LG THERMA V DHW Tank Kit Installation Manual

INSTALLATION MANUAL
AIR-TO-WATER
HEAT PUMP
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
Please retain this installation manual for future reference after reading it
thoroughly.
DHW Tank Kit
PHLTA, PHLTC
MFL62047301
Rev.07_040521 Copyright © 2012 - 2021 LG Electronics Inc. All Rights Reserved.
Safety Precautions
• If the product was submerged under water, ask the service
center for instruction. It may cause fire or an electric shock
unless you do that.
• For electrical work, contact the dealer, seller, a qualified
electrician, or Authorized Service Center.
CAUTION
!
• Make sure children or senor citizens use the product under
proper observation in order to prevent safety accident.
• Do not subject the product to shock. It will cause product
breakdown.
• Do not pick the product with a sharp tool. It may cause product
breakdown with the damage to its parts.
• Do not clean the product with strong cleanser such as solvent.
Use soft clothes in order to prevent fire or product deformation.
• Do not touch the product with a wet hand. Do not pull the lead
cable. It may cause product breakdown or an electric shock.
• Do not install the unit in potentially explosive atmospheres.
Disposal of your old appliance
1. This crossed-out wheeled bin symbol indicates that waste elec-
trical and electronic products (WEEE) should be disposed of
separately from the municipal waste stream.
2. Old electrical products can contain hazardous substances so
correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
Your old appliance may contain reusable parts that could be
used to repair other products, and other valuable materials that
can be recycled to conserve limited resources.
3. You can take your appliance either to the shop where you pur-
chased the product, or contact your local government waste of-
fice for details of your nearest authorised WEEE collection
point. For the most up to date information for your country
please see www.lg.com/global/recycling
Safety Precautions
Safety Precautions
To prevent injury to the user or other people and property damage, the
following instructions must be followed.
• Incorrect operation due to ignoring instruction will cause harm or
damage. The seriousness is classified by the following indications.
!
This symbol indicates the possibility of death or serious injury.
!
This symbol indicates the possibility of injury or damage.
!
Installation
• ELCB(Electric Leakage Circuit Breaker) should be installed for
safety.
• Entrust installation of the product to the service center
because improper installation may cause fire, an electric shock,
explosion, and physical injury.
• Use the original parts in order to prevent fire, an electric shock,
explosion, and product breakdown.
• Keep combustible and/or inflammable materials away from the
product in order to prevent fire or product breakdown.
• Do not disassemble, repair, or modify the product at your
discretion in order to prevent fire or an electric shock.
• Do not install the product in wet and humid areas in order to
prevent product breakdown.
• Do not drop water on to the product. It may cause an electric
shock or product breakdown.
www.lg.com
Part Description
Part Description
MCCB(Molded Case
(For connecting MCCB
Fixing Screw for Magnetic
Bracket (For PHLTA)
Bracket (For PHLTC)
Fixing Screw for Bracket
WARNING
CAUTION
WARNING
Item
Circuit Breaker)
&
Magnetic Contactor
Thermistor Sensor
Cable
with terminal block)
Contactor
Installation Manual
Image Quantity (EA)
1
1
2
2
1
1
1
2
