PRODUCT NO.
BASE MODEL NO.
FEF362MXAWA
FEF362MXA
SERVICE DATA SHEET - # 316259186
WIRING DIAGRAM - #316255137
OWNER'S GUIDE - # 316257105
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
black/white
North America
Publication No.
5995381422
021113
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF362MXA
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FEF362MXA
Summary of Contents for Frigidaire FEF362MXA
- Page 1 PRODUCT NO. BASE MODEL NO. FEF362MXAWA FEF362MXA SERVICE DATA SHEET - # 316259186 WIRING DIAGRAM - #316255137 OWNER’S GUIDE - # 316257105 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 COLOR MARKET black/white North America FEF362MXA Publication No.
- Page 2 Publication No. FEF362MXAWA 5995381422 BACKGUARD 11/02...
- Page 3 POS. NO 20 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF362MXAWA BACKGUARD PART NO DESCRIPTION 316239900 Shield,backguard ,rear wall 316241000 Shield,end cap ,RH 316241001 Shield,end cap ,LH 316022500 Light/Lamp,indicator ,125 V 316220216 Support,backguard ,black ,RH 316220217 Support,backguard ,black ,LH 316240904...
- Page 4 Publication No. FEF362MXAWA 5995381422 BODY 11/02...
- Page 5 POS. NO 12 # 18 # 37 # 62 # 66 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF362MXAWA BODY PART NO DESCRIPTION 316201300 Back,main 316230114 Panel,bodyside ,white ,RH 316230115 Panel,bodyside ,white ,LH 316021131 Screw,bodyside ,8-18 X 11/16 ,white 316129200...
- Page 6 Publication No. FEF362MXAWA 5995381422 TOP/DRAWER 11/02...
- Page 7 POS. NO 15 # 15A# # = Fast-moving Parts * = Non-Illustrated Parts FEF362MXAWA TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 3051163 Glide,drawer ,rear 316010206 Element,surface ,8" ,2200 W ,radiant 316010205 Element,surface ,6" ,1200 W ,radiant 316251920 Main Top Assy,glass/steel ,white 316235900...
- Page 8 Publication No. FEF362MXAWA 5995381422 DOOR 11/02...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF362MXAWA DOOR PART NO DESCRIPTION 5303935191 Trim kit-door,3 sided ,black ,w/tape and foil 5303935203 Glass,door kit ,black ,outer ,w/foil tape 316088700 Glass,oven door ,airwash 316222706 Shield,wool ,oven door 316236800 Insulation,oven door 316088600 Glass,oven door ,inner 316230604...
-
Page 10: Wiring Diagram
Publication No. FEF362MXAWA 5995381422 WIRING DIAGRAM 11/02... -
Page 11: Wiring Schematic
FEF362MXAWA Publication No. 5995381422 WIRING SCHEMATIC # = Fast-moving Parts 11/02 * = Non-Illustrated Parts...
