- Page 1 MANUAL OF INSTRUCTIONS ELECTRONIC FORCE GAUGE FOR HOIST MODEL “PEV-1” 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 2 MANUAL OF INSTRUCTIONS DESCRIPTION The PEV-1 weighing hoist is an electronic weighing system of great precision, designed to hang on any type of crane. The advantages offered by this system are that it allows to read the lifted charge at the very moment, without having to move it to a fixed weighing machine.
- Page 3 RANGE OF TEMPERATURE –10ºC... +40ºC. MAXIMUM WEIGHT OF BOTTOM OF SCALE PLUS 6 DIVISIONS. CONSUMPTION STANDBY 8 uA, AT WORK 40 mA FULFILLS THE O.I.M.L. SPECIFICATIONS 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 4 [ oFF ] [bAtEr] [b8.3v] Voltage of the battery. Press again on the key (ON/OFF) or (6) to come back to the normal mode of work: [ PESo] 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 5 The visor will show us the weight of the tare in negative: [ -150] Weight of the tare. Different weighings can be done keeping automatically the value of the tare. 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 6 Pressing on key (->0<-/B) or key (2), we will be able to visualize again the value of the net weight: [ nEto] [ 2400] Net weight. 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 7 To end the series of present weighings and to vizualise the accumulated total, press key (5)[TOTAL] of remote control: [TOTAL] Press key (5) [TOTAL]. [ 7132] 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 8 The uploader has to be connected with a plug of 220 V c.a. during 8...12h. THE LIFE OF THE BATTERIES DIMINISHES IN THE FOLLOWING CASES: - When uploads are superior to 12 hours. 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
-
Page 9: Configuration Of Parameters
Increase value digit/change selection. Decrease value digit/change selection. [ START ]. Go to beginning of the menu. [ END ]. Leave the parameter and/or the menu. 09/2021 VERLINDE reserves the right to alter or amend the above information without notice... - Page 10 [IMPno] Printer disconnected. [IMPSI] Printer connected. [tIqUE] Type of ticket. [PArCI] Ticket of partial weighings. [UnICo] Ticket of individual weighings. [CodbA] Ticket of bar code EAN13. 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 11 -[CoPSI] Ticket of copy activated. -[CoPno] Ticket of copy disconnected. [rELoJ] Adjustment of date and hour. (00…31). -[dIAnn] -[MESnn] Month (01…12). -[Añonn] Year (00…99). -[Hornn] Hour (00…23). -[MInnn] Minute (00…59). 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 12 1 FUNC. 2 FUNC. 3 FUNC. 4 FUNC. 5 FUNC. 6 FUNC. TARE TARE TARE TARE TARE TARE ZERO ZERO ZERO SENDIN SENDIN SUBTO SUBTO TOTAL TOTAL 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 13 MANUAL OF INSTRUCTIONS Conditions of guarantee. VERLINDE guarantees this device during a period of 12 months, after the date of adquisition, in the following way: Covering whichever defect of fabrication or defect of origin, as well as the totality of its components, including the labour for the substitution of the faulty pieces, in our factory.
- Page 14 UNE-EN 12077-2 General Security of Machines Inspired in the governing rules of the Official Gazette of the European Communities: 98/37CE Rule General Security Machines Authorised by: Francois Gurniki Signature 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
- Page 15 MANUAL OF INSTRUCTIONS Equipment: Electronic force gauge for hoist. Model: PEV-1. Verification of functioning / Calibration: Serial number: 09/2021 VERLINDE reserves the right to alter or amend the above information without notice...
