UMENA PROSOLAR PATHMASTER User Manual

PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE

SPECIFICATIONS

Wattage: 6W
Lamp: In-built Sanan 2835 LED Chips 12*0.5w (120˚ Beam Angle)
Colour Temperature: 6000K (Daylight White)
Lumen Output: Approx. 300 lm
LED Life Expectancy: up to 25,000 hours / 5 years
Concentrated Light Spread (diam.): 1.5m (450mm) / 2m (700mm)
Mounting spacing: 1-2m apart (450mm) / 2-3m apart (700mm)
Sensor: Light / Charge Sensor
IP Rating: IP65
Battery Type: Lithium - LiFePO4 3.2v/8Ah (replaceable)
Battery Charge Time: 5-8 hrs full sunshine (approx.)
Lux Level (LED On/Off): 15 Lux
Max Illumination Time at Full Charge: Over 50 hrs
Solar Panel: 5v / 25W Single Silicon Solar Panel
Materials: Die Cast Aluminium & UV Stop Polycarbonate
Weight: 2.1KG / 2.4KG (approx.)
Mounting: External Surface Mount / Ground Spike
Lighting Function: 1hr 100%, 1 hr 80%, 1 hr 60%, 4 hrs 40%, 5hrs 20%, OFF
Working Temperature: -25˚C ~ 55˚C
Included: Surface Mount, Anchor Bolts, Ground Spike,
Allen Key (for turning on/off only)
•
If a fitting is found to be damaged, cease use immediately.
•
The unit may get warm whilst on for a period of time.
•
Always take care when installing your solar light.
•
Fitting must be mounted to a solid surface or using relevant anchor bolts / J-Bolts
•
This Solar Light will not charge correctly if the panel is behind glass or artificial light is used.
•
Ensure the waterproof bung is in place at all times, other than when turning the unit on or off.
•
Due to temperature difference in and outside the fitting, condensation may be present internally but will not affect use.
CLEANING & MAINTENANCE:
Occasional cleaning and care is recommended for this product. Wipe with a soft, slightly damp cloth to remove any surface dirt.
To maintain efficiency, specifically clean the solar panel and polycarbonate lens on a regular basis. Also, keep the solar panel free
of debris and snow to prevent reduced battery life or malfunction. Do not use abrasive cleaners or a lot of water as this could
damage the fitting. Please refer to our website for more information on the best way to clean different materials.

RETURNS:

rd
If purchased from a 3 party, please contact your supplier. If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us
for more information. Please recycle packaging whenever possible.
PATHMASTER 450mm / 700mm Solar Post Light
THANK YOU FOR YOUR PURCHASE
Full product range & more information: www.lumenalights.com
External Base / Ground Spike

WARNINGS

Tel: +44 1327 871161
USER MANUAL
260 mm
450mm
or
700mm
✔✔✔✔✔
5 YEAR
GUARANTEE
see website for
more details
118 mm
unless ground spike is used.
,
Email: sales@lumenalights.com
90mm
