- Page 1 104 Head up series essential Owners manual twin twin xl Advisory Setup Installation & 1 year warranty...
-
Page 2: Technical Support
TECHNICAL SUPPORT If you have ANY trouble assembling the unit, please email info@thebedboss.com or call our technical support at 423-521-2614. Leave a message and one of our representatives will contact you as soon as possible. WARNING Attention: Read the following information before using this product. Failure to use a surge protection device could compromise safety or cause product malfunction and could void the electrical portion of your warranty. -
Page 3: Setup And Installation
To access step-by-step video instructions search “Bed Boss” on YouTube.com Setup and Installation Important: We strongly recommend two able-bodied adults set up and assemble this product. Check and verify all parts are included before discarding any packaging materials. All electronics and components that need to be installed are located in boxes or directly attached to the frame. - Page 4 Setup and Installation Setup and Installation Setup and Installation Setup and Installation Setup and Installation Setup and Installation Setup and Installation Figure 1 Figure 1 Figure 1 Figure 1 Figure 1 Figure 1 See Figure 1. Attach (2) arm mounting brackets (E) to the See Figure 1.
- Page 5 Setup and Installation See Figure 3. Complete the arm assembly by tightening M8 nuts and M8*50 screws on the arm mounting brackets. Finished arm assembly should appear as shown. Figure 3 Figure 4 M8*20 See Figure 4. Attach the motor mount (C) using (2) M8*20 screws as shown.
- Page 6 Setup and Installation Setup and Installation Figure 5 See Figure 5. Attach (1) center leg (H) using (2) M8 nuts and (2) M8*45 screws as shown. Note the center leg is designed Figure 5 to have some movement from front to back and to adjust M8*45 height.
- Page 7 Setup and Installation Figure 7 See Figure 7. Attach the motor (B) as shown using (2) M10 nuts and (2) M10*50 screws. Make sure the motor is mounted exactly as shown in the photo. M10*50 IMPORTANT: Secure the connection where the remote connects to the motor.
-
