- Page 1 104 Head up series essential Owners manual Full queen king Advisory Setup Installation & 4 year warranty &...
- Page 2 WARNING Attention: Read the following information before using this product. Failure to use a surge protection device could compromise safety or cause product malfunction and could void the electrical portion of your warranty. WEIGHT UNITS Electrical surges are by far the biggest cause of problems with electrical circuits.
- Page 3 Setup and Installation Important: We strongly recommend two able-bodied adults set up and assemble this product. Check and verify all parts are included before discarding any packaging materials. All electronics and components that need to be installed are located in boxes under the bed base or attached to the frame.
- Page 4 Setup and Installation Figure 1 Attach (2) arm mounting brackets (G) as shown using (4) M8 nuts and (4) M8*50 screws. Brackets should face head of the bed. Do not tighten at this time—this will allow ease of M8*50 attaching the arm assembly. (See Figure 1.) Slide the arm assembly (J) into either arm mounting bracket and attach with (1) M10 nut.
- Page 5 Setup and Installation Mount the long rail (B) as shown using (4) M8*20 screws. (See Figure 4.) M8*20 Figure 4 Attach the arm support bracket (C) using (4) M8*20 screws and (4) washers as shown. (See Figure 5.) M8*20 Figure 5 Figure 6 M8*20 Attach the motor mount (F) using (4) M8*20 screws as...
- Page 6 Setup and Installation Figure 7 Attach (1) center leg (I) with the center support bracket (D) using (2) M8 nuts and (2) M8*20 screws as shown. Note the center leg is designed to have some movement from front to M8*20 back and to adjust height.
- Page 7 Setup and Installation Figure 9 Attach the motor (K) as shown using (2) M10 nuts and (2) M10*50 screws. Make sure the motor is mounted exactly as shown in the photo. (See Figure 9.) M10*50 Figure 10.1 Figure 10.2 Figure 10 Flip the adjustable on its legs and attach the fl...
- Page 8 THE BED BOSS® - 1 & 4 YEAR LIMITED WARRANTY 4 YEAR LIMITED PARTS WARRANTY Congratulations on the purchase of your new adjustable bed base from THE BED BOSS® covered by the best warranty Upon written notice during the second year through the from THE BED BOSS®.
