Summary of Contents for Julian Bowen RIA302
- Page 1 ASSEMBLY FABRIC STORAGE BED 150 CM INSTRUCTIONS Approximate Assembly Time People Required to Assemble NO Extra Tool Required Version Number - 1.0 Product Code - RIA302...
- Page 2 NO Extra Tool Required Contact Retailer...
- Page 3 Please check all hardware matches the list below. Should you notice any are missing please contact your retailer. PARTS HARDWARE M8 x 25mm (12 PCS) NUT (2 PCS) M6 x 30mm (6 PCS) M6 x 15mm (12 PCS) M6 x 68mm (2 PCS) FLAT WASHER (12 PCS) SPRING WASHER (12 PCS) 5mm ALLEN KEY (1 PC)
- Page 4 Please ensure you carefully check all the pieces, should you have any concerns please contact the retailer before assembly commences. Please have your order number, details of the issue, the product code, and the batch number from the cartons as this will help us to resolve your issue much faster.
- Page 6 Attaching side rails to headboard. & Repeat step 1 for footboard. Before tightening the bolts, please ensure the bed frame is square.
- Page 7 &...
- Page 8 Secure hydraulic arms Before connecting the hydraulic arm, ensure the lifting mechanism is functioning correctly - it should lift up and down freely with adequate clearance on all sides. DO NOT OVERTIGHTEN THE NUTS ! Assemble the base 3&4...
- Page 9 Attach non-woven fabric dust cover rst, then adjustable legs. Assemble slats...
- Page 10 Attach belt to the metal frame by loop-on method as shown, pull tight after loop-on. Place the mattress onto the frame. (MATTRESS NOT INCLUDED) Notes: It is imperative that the bed is aligned squarely to prevent the frame from catching on and damaging the upholstered side rails. Please use extra caution when opening and closing the bed, ensure a similar spacing on each side of the frame.
-
Page 11: General Care And Maintenance
GENERAL CARE & MAINTENANCE We advise that when cleaning the product that a damp cloth is used. Avoid the use of all household cleaners and abrasive. Never push or drag the furniture. Never attempt to move the furniture when fully loaded. We advise that periodically all fixing are re-tightened.
