SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS
SERVICE MANUAL
Indoor unit
[Model names]
[Service Ref.]
PKA-A24KA.TH
PKA-A24KA
PKA-A30KA.TH
PKA-A30KA
PKA-A36KA.TH
PKA-A36KA
PKA-A24KAL.TH
PKA-A24KAL
PKA-A30KAL.TH
PKA-A30KAL
PKA-A36KAL.TH
PKA-A36KAL
INDOOR UNIT
TEMP.
ON/OFF
WIRED REMOTE
CONTROLLER
COOL
DRY
AUTO
FAN
HEAT
WIRELESS REMOTE
CONTROLLER
CONTENTS
1. REFERENCE MANUAL ................................... 2
2. SAFETY PRECAUTION ................................... 3
3. PART NAMES AND FUNCTIONS ................... 4
4. SPECIFICATIONS ............................................ 7
5. NOISE CRITERION CURVES .......................... 8
6. OUTLINES AND DIMENSIONS ....................... 9
7. WIRING DIAGRAM .........................................10
8. REFRIGERANT SYSTEM DIAGRAM ............ 11
9. TROUBLESHOOTING .................................... 12
10. SPECIAL FUNCTION ..................................... 26
11. DISASSEMBLY PROCEDURE ....................... 29
PARTS CATALOG (OCB457)
3 3 2 2 3
March 2009
No. OCH457
NOTE:
• This manual describes
only service data of the
indoor units.
• RoHS compliant products
have <G> mark on the
spec name plate.
