AL-81860
UtiliStool
Parts Listing
A
Stool Seat
1 Unit
B
Gas Lift
1 Unit
C
Gas Lift Bellows
1 Unit
D
5-Star Base
1 Unit
E
Casters
5 Units
WEIGHT CAPACITY: 250 lbs.
CAUTION:
1. Do not use this stool as a step ladder.
2. Check for loose screws and tighten them every 6 months.
A
Assembly Instructions:
C
Tools Needed: Philips Head Screwdriver
STOP
Please read all instructions before assembly.
Step 1: Insert Casters (E) into 5-Star Base (D).
If you are assembling a model with a Foot Ring please proceed to
STOP
subsequent pages for drafting kit assembly instructions.
Step 2: Insert Gas Lift (B) into 5-Star Base (H).
Step 3: Cover Gas Lift (B) with Gas Lift Bellows (C).
Step 4: Carefully place Stool Seat (A) onto the Gas Lift (B),
aligning the holes. Press down on Stool Seat (A)
B
to secure onto 5-Star Base (D).
D
E
04.29.2014
