Hardware Quick Installation Manual
Packing List
AP(1)
Mounting Kit(1)
1
Equipment Introduction
Device Port and Indicator
2
No
Name
Ethernet Port（48V POE）
1
ETH
Reset Button: Press to Restart;
2
Reset
Press more than 5 seconds to
reset to factory default
icXchange ICX200WAP
ICX200WAP
Mounting Plate(1)
M4X30(2)
Quick Installation
Manual(1)
1
Description
Plastic Wall
Anchor(3)
5
6
No
Name
Light Always On: System Normal
3
PWR
Light Always On: Wireless enabled
4
WLAN
Light Flash: Data is transferring
Light Always On: Wireless
5
ETH
connection stable
Light Flash: Data is transferring
Reserved LED
6
ST4.2X25(3)
4
3
Description
