HANYOUNG NUX T Series Instruction Manual

T series
Turn Light
INSTRUCTION MANUAL
Thank you for purchasing Hanyoung Nux products. Please read the
instruction manual carefully before using this product, and use the product
correctly. Also, please keep this manual where you can view it any time.
▍ Safety information
Please read the safety information carefully before the use, and use the product correctly.
The alerts declared in the manual are classified into Danger, Warning and Caution according to their importance
DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor injury or properties damage
DANGER
• Be sure to turn off the power before wiring as there is electric shock danger.
WARNING
• Be sure to check the power voltage before installing the product,
as overvoltage may cause breakdowns.
• Do not change the specifications of the product or assemble
parts of other products, as doing so may cause breakdowns.
• Be sure to insulate the unused wire terminals.
• Since this product is not equipped with a power switch and fuse,
install them separately on the outside
• If there is a possibility that a breakdown or abnormality of this
product may lead to a serious accident to the system, install an
appropriate protection circuit on the outside.
▍ Suffix code
Model Code
T ⃞ - ⃞ ⃞ ⃞ ⃞ -
060
084
Dimensions
100
150
P
Cap shape
F
A
Functions
F
D12
D24
Power voltage
A110
A220
R
Y
Cap Colors
G
A
Mount
▍ Connection diagram
The connection diagram for each power voltage is as follows.
The buzzer with built-in buzzer is connected to the power line.
Power voltage
12Vd.c.
24Vd.c.
110Va.c. 50/60Hz
220Va.c. 50/60Hz
▍ Installation method
Indoors
○ ○
• This product is manufactured with a general structure for indoor use. You can install it in any direction when using it indoors.
• When using it outdoors, install it in vertical forward direction in places with limited rainwater infiltration.
• If possible, install it in a places with low moisture, dust, vibrations or impacts.
▍ Dimension and panel cutout
Model
T060-P⃞⃞⃞- D
T060-F⃞⃞⃞- D
T060-P⃞⃞⃞- M
T060-F⃞⃞⃞- M
HANYOUNGNUX CO.,LTD
28, Gilpa-ro 71beon-gil,
Michuhol-gu, Incheon, Korea
TEL : +82-32-876-4697
http://www.hynux.com
CAUTION
• This product is for indoor use only. Use it in places without water.
• Wire correctly referring to the connection diagram, as wrong
wiring may cause breakdowns or light failures.
• Any use of the product other than those specified by the
manufacturer may result in personal injury or property damage.
• Do not pull the wires that come out of the product strongly, as it
may cause disconnections, short circuits, or other breakdowns.
• Excessive shocks to the product may cause breakdowns or
damages.
Content
⃞ Turn light
Ø 60
Ø 84
Ø 100
Ø 150
Round cap ※except Ø150 model
Square cap
Rotating continuous light
Rotating continuous light / Buzzer
12Vd.c.
24Vd.c.
110Va.c.
220Va.c.
Red
Yellow
Code extended hole
Green
Blue (only with Ø 84 model)
fixing hole
D Direct installation type (basic type)
Supporter installation type
M
※ only with Ø60/Ø84 models with rotating continuous light
Wiring color
White (+), Black (-)
Code extended hole
Black - White ( when using 110Va.c. )
Black - Red ( when using 220Va.c. )
fixing hole
Outdoors
○ ○ X
Code extended hole
fixing hole
Code extended hole
fixing hole
Dimension and panel cutout
Code extended hole
fixing hole
Code extended hole
fixing hole
Code extended hole
fixing hole
Supporter : STM-84
(optional)
ML0503KE200129
T084-P⃞⃞⃞- M
T084-F⃞⃞⃞- M
T084-P⃞⃞⃞- D
T084-F⃞⃞⃞- D
T100-P
T100-F
T150-F
▍ Supporter dimension
Shape
STM-84 (optional)
STM-105 (optional)
X
ST-013 (optional)
MTM-98 (optional)
SP-1 (optional)
SP-2 (optional)
fixing hole
Code extended hole
Code extended hole
Using model Dimension and panel cutout
T060
T084
T100
fixing hole
T084
T100
T100
Ø18
T060
T084
Ø 60
3- Ø4.2
PCD Ø 40
판넬가공 Min. Ø 5
T060
T084
fixing hole
fixing hole
fixing hole
fixing hole
Code extended hole
fixing hole
fixing hole
※ Optional configuration
fixing hole
fixing h
Ø60
3- Ø4.2
PCD Ø40
Panel Processing
Min.
Ø5
