SIENA LOVESEAT - S52
ASSEMBLY INSTRUCTIONS
COMPONENTS
HARDWARE
Long Bolt
A
Quantity: 2
8mm Dowel
E
Quantity: 12
FINISHING ITEMS
Medium Grit Sandpaper
Note: Hardware pack may contain extra hardware
NOTE: If the furniture is going to be placed on a concrete or tile patio, it should first be rinsed well to
remove the sawdust that may cause some staining.
15 Kingbrook Parkway, Suite 100 Simpsonville, KY 40067 p. 877.866.3331
2
Short M6 x 35 mm Bolt
B
Quantity: 6
Wood Screw
F
Quantity: 1
3
C
Guiding Bolt
Quantity: 1
G
Allen Wrench
Quantity: 2
4
Barrel Nut
D
Quantity: 1
f. 502.719.8888 oxfordgarden.com
Ver. 06.30.20
