- Page 1 Synapse 2GM100-2HM100 3Gb/s, HD, SD SDI Dual channel VANC analyzer Installation and operation manual Original manual V1.0 COPYRIGHT 2017 Axon Digital Design BV 2017 ©...
-
Page 2: Preface
NEVER operate this product in an explosive atmosphere. Warranty: Axon warrants their products according to the warranty policy as described in the general terms. That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not removed. -
Page 3: Table Of Contents
When Powering-up..................7 Changing settings and parameters.............. 7 Front Panel Control................... 7 Example of changing parameters using front panel control......7 Axon Cortex Software................8 Menu Structure Example................9 4 Introduction....................10 4.1 Block schematic & I/O panel..............10 4.2 Features....................11 4.3 Applications.................. - Page 4 mIP0..................... 16 mNM0....................16 mGW0....................16 NetwPrefix0.................... 16 6 Status......................17 6.1 Introduction..................17 6.2 2GM100 - 2HM100 status items.............. 17 sInp1....................17 SDI1DemFrmt01/02 ~ SDI1DemFrmt15/16..........17 SDI1AudioStat..................17 sInp2....................18 SDI2DemFrmt01/02 ~ SDI2DemFrmt15/16..........18 SDI2AudioStat..................18 Ref......................18 CPU_Env_Temp..................18 CPU_Core_Temp..................
-
Page 5: Introduction To Synapse
Although not required to use Cortex with a Synapse frame, you are strongly advised to use a remote personal computer or laptop PC with Axon Cortex installed, as this increases the ease of use and understanding of the modules. Introduction to Synapse... -
Page 6: Unpacking And Placement
Unpacking and Placement Unpacking The Axon Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 7: Quick Start
Changing settings The front panel controls or the Axon Cortex can be used to and parameters change settings. An overview of the settings can be found in chapter 5, 6 and 7 of this manual. -
Page 8: Axon Cortex Software
To edit the setting of the menu item press ▲ or ▼. All menu items can be monitored and/or changed in this way. Changing a setting has an immediate effect. Axon Cortex Synapse Cortex can be used to change the settings of Software Synapse modules from a PC, either locally or remotely. -
Page 9: Menu Structure Example
Synapse module and displays it on a GUI. The software has an intuitive structure following that of the module that it is controlling. For operation of Axon Cortex, please refer to the Cortex help files. Menu Structure... -
Page 10: Introduction
Introduction Block schematic & I/O panel Introduction... -
Page 11: Features
Features The 2GM100 and 2HM100 are VANC data analyzers with an application in mind where the data is monitored on screen in the SDI domain. Monitoring the data through ACP and SNMP is also possible. The different VANC signals are decoded and displayed as an overlay on the SDI output. -
Page 12: Applications
■ ANC LTC decoded ■ Drop/non drop ■ Frames per second ■ SCTE104 ■ WHP296 extension to SCTE104 ■ Subtitle timing (delay/not delay) ■ Subtitle mode (live/not live) ■ DOG Logo insert mode ■ Locks to SDI input, or external reference ■... - Page 13 DC offset 0V ±0.5V Rise/Fall time 135ps nominal Overshoot < 10% of amplitude Return loss > 15dB up to 1.5GHz (typ) Wideband jitter < 0.2UI Ethernet Standard 10Base-T, 100Base-Tx IEEE 802.3 Connector 8P8C VANC standards Standard SCTE104-2014, SMPTE2010 Miscellaneous Weight Approx.
-
Page 14: Settings
Settings Introduction The settings menu displays the current state of each GEE-HEE2x0 setting and allows you to change or adjust it. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex. Also the SCP08 control can be used. -
Page 15: Ov_Rt_Scte_104
you decide in which corner the realtime analyzer window is displayed. The real time analyzer contains information about the video format, ATC timecode, Payload, embedded audio, teletext, AFD and SCTE104. Can be Top-Left, Top-right, Bottom-Left or Bottom-Right. You can also decide to switch the realtime analyzer window off entirely. -
Page 16: Wst-Page_2
Auto in which case the card chooses the data according to this priority list: S2016 -> WSS -> VI. Default is Auto. WST-Page_2 With this setting you decide which S2031, OP47 or WST-B page should be decoded in the Teletext window of channel 2. By default it is set to 888 (the standard subtitles page). -
Page 17: Status
Status Introduction The status menu indicates the current status of each item listed below. 2GM100 - 2HM100 status items sInp1 This status item indicates the presence and format of a valid signal on input 1. This is displayed as: ■ 1080p60 ■... -
Page 18: Sinp2
2 is Clipped, channel 3 is NA (not available) and channel 4 to 16 are Present sInp2 This status item indicates the presence and format of a valid signal on input 2. Displayed the same as described in sInp1. SDI2DemFrmt01/02 These status items indicate the detected audio format of each corresponding audio pair in the de-embedder of SDI SDI2DemFrmt15/16... -
Page 19: Network Status
Network status IP_Addre0 This item displays the status of the IP address. It can be Manual, DHCP Asking, DHCP Leased or DHCP Infin. MAC0 This item displays the MAC address of the card. This item displays the current IP address of the card. This item displays the current netmask of the card. -
Page 20: Events Menu
Events Menu Events Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the goal of The goal of events is to inform the environment about an event? a changing condition on the card. -
Page 21: Defining Tags
Defining Tags The tags defined for the 2GM100-2HM100 are: Event Menu Item Description Announcements 0 or NA 0 or NA Announcement of report and control values Events Menu... -
Page 22: Gnu Public License
License is included below. Under this license you are eligible to receive a copy of the source code of this software including any changes. Axon Digital Design B.V. shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs. - Page 23 on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program.
- Page 24 extend to the entire whole, and thus to each and every part regardless of who wrote it. Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.
- Page 25 executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.
- Page 26 of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program. If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
- Page 27 10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
-
Page 28: Index
Index AFD-Sel_1 AFD-Sel_2 Out-Frmt An Introduction to Synapse Output1-Overlay Announcements OV_RT_SCTE_104 AXON Digital Design Website OV_RT-Analyzer OV_Teletext OV_Video CPU_Core_Temp CPU_Env_Temp Remote Control Capabilities FPGA_Core_Temp FPGA_Env_Temp FPGA_Fan SDI1AudioStat FS_RT-Analyzer SDI1DemFrmt FS_RT-SCTE104 SDI2AudioStat FS_Teletext SDI2DemFrmt sInp1 sInp2 WST-Page_1 IP_Addre0 WST-Page_2 IP_Conf0 Local control Panel... - Page 29 Index...
- Page 30 Hercules 28 NL-5126 RK Gilze The Netherlands +31 161 850 450 +31 161 850 499 www.axon.tv info@axon.tv...
