- Page 1 GIX100-110 HIX100-110 Dual channel 3Gb/s, HD, SD integrity checking probe with optional clean audio (2x1) switch-over function Installation and Operation manual...
- Page 2 TECHNICAL MANUAL GIX100-110 HIX100-110 Lange Wagenstraat 55 NL-5126 BB Gilze The Netherlands Phone: +31 161 850 450 Fax: +31 161 850 499 E-mail: Info@axon.tv Web: www.axon.tv...
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: Axon warrants their products according to the warranty policy as described in the general terms. That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
Unpacking Placing the card A Quick Start When Powering-up Changing settings and parameters Front Panel Control Example of changing parameters using front panel control Axon Cortex Software Menu Structure Example The GIX-HIX100-110 Card Introduction Features Applications Block schematic Settings Menu... - Page 5 Silence-Level Dly_Frmt_Prst #F-delay_1 #V-Delay_1 #H-Delay_1 Delay-Status LockMode Ref-Type P60-P50_Sync Input_Loss_A Input_Loss_B NonPCM-Bypass Audio-Phase AudioStatusBits Audio_Ctrl Audio_Preset #Audio_Delay Emb_Prst_Default #Emb-Mode #EmbA_Grp ~ #EmbB_Grp #SourceEmb-A1 ~ #SourceEmb-D4 #EmbA1_Inp_Ch ~ #EmbD4_Inp_Ch Contact _1 ~ Contact_7 GPI_A-mode ~ GPI_D-mode GPI_A-Take ~ GPI_D-Take IP_Conf0 mIP0 mNM0 mGW0 NetwPrefix0...
- Page 6 Events Menu Introduction What is the Goal of an event? GIX-HIX100-110 Events Announcements Ref-Status Input_A Input_B TRS-Status_A TRS-Status_B Active_Out_A Active_Out_B Freeze-Status_A Freeze-Status_B Black-Status_A Black-Status_B Audio-Data_A Audio-Data_B GENERIC_1 GENERIC_2 GENERIC_3 GENERIC_4 GENERIC_5 GENERIC_6 GENERIC_7 GENERIC_8 What information is available in an event? The Message String The Tag Defining Tags...
-
Page 7: Introduction To Synapse
SYNAPSE FRAMES Although not required to use Cortex with a Synapse frame, you are strongly advised to use a remote personal computer or laptop PC with Axon Cortex installed, as this increases the ease of use and understanding of the... -
Page 8: Unpacking And Placement
Unpacking and Placement Unpacking The Axon Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 9: A Quick Start
Changing settings and The front panel controls or Axon Cortex Software can be used to change parameters settings. An overview of the settings can be found in chapter 5, 6 and 7 of this manual. -
Page 10: Example Of Changing Parameters Using Front Panel Control
Example of changing With the display as shown below parameters using front panel control RRC18 [Select Card] >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 11: Axon Cortex Software
Axon Cortex Software can be used to change the settings of Synapse Axon Cortex Software modules from a PC, either locally or remotely. The software enables communication based on TCP/IP between the setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items. -
Page 12: The Gix-Hix100-110 Card
The GIX-HIX100-110 Card The GIX100-110 and HIX100-110 are dual channel high performance Introduction 3Gb/s, HD and SD SDI video and embedded audio probes (signal integrity monitor) with clean video switch-over function. The switch function can be triggered by any of the integrity controls or by GPI. -
Page 13: Applications
The GIXxxx family can be used as station output card, and ingest Applications quality control card or a generic 2 x 2 switch. The integrity checking can also be performed for alarm monitoring purposes with the switch function disabled. ... -
Page 14: Settings Menu
Settings Menu Format Allows you to set what the input format is on inputs A and B. Both inputs need to have the same format. Possible settings are: 1080p60, 1080p50 (GIX only) 1080i60, 1080i50 1080p30, 1080p25 1080p24, 1080p24sf ... -
Page 15: Switch-Back
inverts the route. Value 0 returns control to the menu item, thus returns to either input A or input B. Auto-GPI only applies when used as backup-switch in 2x2 mode (Output-Config setting). Assumed is that Input-A is the main channel, Input-B is the backup. GPI contact 1 forces the Output-A to Input-B, regardless of an error condition for this input. -
Page 16: Testpatterna
TestPatternA With this setting you can enable a test pattern as frame synchronizer output on channel A. Can be a Colorbar or a Zoneplate. TestPatternB With this setting you can enable a test pattern as frame synchronizer output on channel B. Can be a Colorbar or a Zoneplate. FS_Gen-Speed This sets the speed of the colorbar or zoneplate generator on a scale from 0 (still) to 15 (fast). -
Page 17: Trs-Error-Det
TRS-Error-Det TRS-Error-Det allows the card to detect if the TRS signals are in the right place. When the amount of misplaced or missing TRS signals have reached the threshold set with TRC_CRC_Thres further down the settings menu an alarm is generated. TRS= Timing Reference Signal. ... -
Page 18: Frz_Nrfrms
Frz_NrFrms When a picture freezes it can be reported by the GIX-HIX100-110. With this item it is possible to determine the sensitivity of this detection. It sets the number of frozen frames before a freeze is reported a freeze. This can be set in a range from 10 to 3000 frames. Default is 100. Frz_Thrs Frz_Thrs determines the sensitivity level of the Freeze-det. -
Page 19: Roi_V-Start
With the V-start setting you define the vertical start position of the ROI_V-start region of interest between 0 and 100% of the total picture height. Default is 0% With the V-stop setting you define the vertical end position of the region ROI_V-stop of interest between 0 and 100% of the total picture height. -
Page 20: Timecode_Ins
Timecode_ins Here you can set if the time code on the inputs should be copied to the (Only in GIX-HIX 110) outputs (on). You can also turn off time code re-insertion. Default is off. S352_Insert S352_Insert enables (on) the Video Payload Identifier insertion in the HANC space. -
Page 21: Audio-Ch-Det
Audio-Det_A1/2 ~ Here you can set per audio channel pair if the status of this audio pair Audio-Det_B15/16 should only be shown, select if the card should switch inputs if PCM is lost (or has silence or clip), or if the selected Dolby AC-3, Enhanced AC-3 or Dolby-E is lost. -
Page 22: Enh-Ac-3-Ch-Det
Enh-AC-3-Ch-Det This item controls the presence detection the embedded Enhanced AC-3 audio pairs. Whenever Enhanced AC-3 is lost on any of the selected Dolby pairs, it is detected as an audio presence error. Off: the functionality is switched off. ... -
Page 23: Clip_Level
Clip_Level Clip_Level determines the level for full scale detection. This can be set in a range from -6dBFS to 0dBFS. The default setting is -0.3 dBFS. This is not a true peak (interpolated) measurement, but a straightforward level comparison. Silence_Det Silence_Det allows the card to detect whether the signal has any PCM channels which have silence for the given Silence-time and Silence-level. -
Page 24: F-Delay_1
#F-delay_1 F-Delay sets the amount of delayed Frames. The available range is from 0 to 125 frames (dependant on the video format). Default is 0F. The preset master for this is Dly_Frmt_Prst, hence the ‘#’-prefix. #V-Delay_1 V-Delay setting allows adjustment of the vertical phase of the output signal with respect to the selected reference input. -
Page 25: Input_Loss_A
Input_Loss_A determines what the output of outputs A is in case of Input_Loss_A lost input: Freeze: a capture of the last good field or frame. Colorbar: a color bar Zoneplate: a zone plate Black: a black output. ... -
Page 26: Audio_Ctrl
Audio_Ctrl This controls the selection of the currently active Audio_Preset. Before using the audio presets, you need to select all audio sources and channels in each preset. To ease this process you can use the Emb- Prst-Default setting to reset all audio presets to factory default selections. -
Page 27: Emb-Mode
#Emb-Mode With Emb-Mode you select how the audio should be embedded into the video: overwrite the exsisting audio, or Append. Default is overwrite. #EmbA_Grp ~ With these settings you select into which audio group (= 4 audio #EmbB_Grp channels) of the outputs you want to embed the corresponding 4 forwarded audio channels, coming from the de-embedder or add-on bus. -
Page 28: Gpi_A-Mode ~ Gpi_D-Mode
GPI_A-mode ~ GPI_D- Selects the mode for the corresponding GPI pool. Possible settings are: mode Prio: Each contact triggers another value, so values are one-hot encoded. Prio_latched: This mode functions like Prio Mode, but the card latches the value. Each contact triggers another value, so values are one-hot encoded. -
Page 29: Status Menu
Status Menu Introduction The status menu indicates the current status of each item listed below. sInp1 ~ sInp4 These items display whether an input is present on inputs 1 to 4. Can be either Present or NA. Displays whether a correct reference is found (Present) or not (NA) INP_FORMAT_A This status item indicates the presence and format of a valid signal for input channel A. -
Page 30: Output-Map
Output-Map This indicates the mapping of the (last known) output when the output format is 3Gb/s (1080p50 or 1080p60). Can be Level A or Level B. When the output format is not 1080p60 or 1080p50, this item indicates CRC_EDH_A Indicates CRC and EDH errors on input A, whenever CRC errors reached the threshold set with TRS_CRC_Thres. -
Page 31: Black-A
Black-A detects whether the input of probe-A is black. Black-A OK: probe-A input signal is not black Error: probe-A input is black No_input: there no input at all on probe-A Off: Black detection is switched off. Same is Black-A, only for probe-B. -
Page 32: Aud-Stat_B1/2
Aud-Stat_B1/2 ~ These status items indicate the detected audio format of each audio pair Aud-Stat_B15/16 in the de-embedder of input channel B. Can be the same formats as listen under Aud-Stat_A1/2. ChA_1_FS ~ ChA_16_FS These items indicate the Full Scale (audio clipping) status of all the individual audio channels of input channel A. -
Page 33: Iodelaya
IODelayA Displays the total delay in ms of framesync output A. Can be a value between 0ms and 15000ms. IODelayB Displays the total delay in ms of framesync output B. Can be a value between 0ms and 15000ms. Contact-Status Displays the currently closed GPI contacts. This is displayed as for (software versions 0709 instance 1010000 when contacts 1 and 3 are closed and for instance and later) -
Page 34: Ip_Addr0
IP_Addr0 This item displays the status of the IP address. It can be manual, DHCP asking, DHCP Leased, DHCP Infin, Disabled or No Cable. MAC0 This item displays the MAC address of the card. This item displays the current IP address of the card. This item displays the current Netmask of the card. -
Page 35: Events Menu
Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of an The goal of events is to inform the environment about a changing event? condition on the card. -
Page 36: Freeze-Status_A
Freeze-Status_A If probe A detects a freeze, an Event will be generated at the set priority. Freeze-Status_B If probe B detects a freeze, an Event will be generated at the set priority. Black-Status_A If probe A detects a black, an Event will be generated at the set priority. Black-Status_B If probe B detects a black, an Event will be generated at the set priority. -
Page 37: What Information Is Available In An Event
GENERIC_9 Probe A Total sum of probed errors. When there's 1or more errors detected, an event is generated at the set priority. GENERIC_10 Probe B Total sum of probed errors. When there's 1or more errors detected, an event is generated at the set priority What information is The message consists of the following items;... -
Page 38: The Priority
GENERIC_1 =GENERIC_1_ON =GENERIC_1_OFF CRC error/ok on probe A GENERIC_2 =GENERIC_2_ON =GENERIC_2_OFF CRC error/ok on probe B GENERIC_3 =GENERIC_3_ON =GENERIC_3_OFF TC error/ok on probe A GENERIC_4 =GENERIC_4_ON =GENERIC_4_OFF TC error/ok on probe B GENERIC_5 =GENERIC_5_ON =GENERIC_5_OFF sum error/ok on probe A GENERIC_6 =GENERIC_6_ON =GENERIC_6_OFF... -
Page 39: Led Indication
LED Indication Error LED The error LED indicates an error if the internal logic of the card is not configured properly, or when there is a hardware failure. Input_1 LED ~ Input_4 These LEDs indicate the presence of a valid SDI (SD or HD) video input signal on each input. -
Page 40: Block Schematic
Block Schematic GIX-HIX100–110 [QUAD SPEED AUDIO BUS] MAIN 3Gb/s, HD, SD IN 1 3Gb/s, HD, SD OUT A1 16 CHANNEL EMBEDDER FRAME-SYNC [BYPASS] TEST PATTERN AUTOPHASER ‘110’ MODELS 3Gb/s, HD, SD IN 2 3Gb/s. HD, SD OUT A2 & ONLY OFFSET DELAY BACKUP SWITCH... -
Page 41: Connector Panel
Connector Panel The GIX-HIX100-110 can be used with the following backplanes: BPH17, BPH17b BPH17 BHX17b 3Gb/s, HD, SD INPUT 1 (OPTIONAL FIBER IN) 3Gb/s, HD, SD INPUT 2 (OPTIONAL FIBER IN) 3Gb/s, HD, SD MAIN OUTPUT 1 (OPTIONAL FIBER OUT) 3Gb/s, HD, SD MAIN OUTPUT 2 GPI I/O 3Gb/s, HD, SD BACKUP OUTPUT 1 (OPTIONAL FIBER OUT) -
Page 42: Gpi Pinning
GPI pinning (software version 0709 and later) Pin 1 GPI input 0 Pin 2 GPI input 1 Pin 3 GPI input 2 or GPO output 0 Pin 4 GPI input 3 or GPO output 1 Pin 5 GPI input 4 or GPO output 2 Pin 6 GPI input 5 or GPO output 3 Pin 7... - Page 43 Note: In case of power failure or when the synapse board is extracted from the frame the bypass is immediately active.
-
Page 44: Switching In 2X2 And 2X1 Modes
Switching in 2x2 and 2x1 modes Appendix 1: The following three tables apply when the switch is configured for Auto Switching in 2x1 mode switching. The Inp-sel setting is auto, the Output-Config is 2x1 and Switch-Back setting is varied for each of these tables. Please read the table from top to bottom, this is the order of the events that occur on the inputs. -
Page 45: Switching In Combined Mode
Switch-Back = On A Input B Input A output B Output Good Good Input A Input B Fail Good Input B Input A Good Good Input A Input B Good Fail Input A Input B Good Good Input A Input B Switch-Back = BackUp_Fail A Input B Input... - Page 46 Switch-Back = BackUp_Fail A Input B Input A output B Output Good Good Input A Input B Fail Good Input B Input B Good Good Input B Input B Good Fail Input A Input A Good Good Input A Input A A Input B Input A output...
-
Page 47: Gpi's Explained
Appendix 2 GPI’s explained This appendix describes the functionality of the GPI’s generally used Introduction within the Synapse based products. The physical contacts of a General Purpose Interface can be assigned by the General functionality user. In our cards the General Purpose Interface contacts (GPI contacts) will be named as General Purpose Input (GPI) or General Purpose Output (GPO). -
Page 48: Take
A-Z depending on the number of pools. The default output value of a pool is always 0. This translates to preset 1 in Axon products. In priority mode, the contact which has the highest priority defines the pool value. -
Page 49: Statuses: Contact Direction
Status Card GPO Pool specific Every GPO pool can be set up to process the input values in two ways. This setting is called GPO_n-Mode and can be set into Priority (Prio) or Binary mode. N is defined as a character in the range from A-Z depending on the number of pools. -
Page 50: Statuses: Gpo Status
Statuses: GPO GPO_n is an integer which reflects the value of the pool. status Example 1: Two We are controlling the up-converter presets using Pool A (Up_CtrlA set pools in binary to GPI_A) and the output mode setting using Pool B (Out-mode-Ctrl mode set to GPI_B). -
Page 51: Example 3: Two Pools In Priority Mode
Set Contact_2 to GPI_A Set GPI_A-Take to Contact_3 Set GPI_B-Mode to Prio Set Contact_4 to GPI_B Set Contact_5 to GPI_B Pool A now consists of GPI 1, GPI 2 and GPI 3 (as take) in binary mode, controlling the up-converter preset. - Page 52 Contact_1 Contact_2 Preset value status status Up-converter Preset 1 Up-converter Preset 1 Up-converter Preset 2 Up-converter Preset 2 (because highest gets priority) Table 9 Pool value in priority mode Pool B now works as follows: Contact_3 Contact_4 Preset value status status Audio Preset 1 Audio Preset 1...
-
Page 53: Gnu Public License Version 2
GNU Public License is included below. Under this license you are eligible to receive a copy of the source code of this software including any changes. Axon Digital Design shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs. - Page 54 Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in objects code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifi cations to it.
- Page 55 NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
