Package Contents

4-PORT PS/2 KVM SWITCH
DKVM-4K
KVM CABLE WITH VGA AND PS/2 (X 2)
CONNECT THE DKVM-4K TO YOUR COMPUTERS
QUICK INSTALLATION GUIDE
If any of these items are missing from your packaging, please contact your reseller.
Installing the DKVM-4K
The DKVM-4K is a hot-swappable KVM switch. You don't need to turn your computers off before
installing the device.
A. Attach your 6-pin PS/2 keyboard connector to the console keyboard port of DKVM-4K.
B. Attach your 6-pin PS/2 mouse connector to the console mouse port of DKVM-4K.
C. Attach your monitor's HDDB 15 VGA connector to the console port of DKVM-4K.
The following steps below apply to each computer that you are using with your DKVM-4K.
D. Attach the KVM cable (keyboard connector) to the PS/2 keyboard port located on the DKVM-4K.
E. Attach the KVM cable (mouse connector) to the PS/2 mouse port located on the DKVM-4K.
F. Attach the KVM cable (VGA connector) to the VGA port located on the DKVM-4K.
G. Attach the KVM cable (keyboard connector) to the PS/2 keyboard port located on the back of
your computer case.
H. Attach the KVM cable (mouse connector) to the PS/2 mouse port located on the back of
your computer case.
I. Attach the KVM cable (VGA connector) to the VGA port located on the back of your computer
case.
Installation of the DKVM-4K is now complete.
