Coaxial loudSpeaker Manual
Manuel de Coaxial
Models: RX4CX, RX46CX, RX5CX RX57CX, RX65CX, RX69CX
Features:
• LAMINATE-TREATED PAPER CONE - Advanced laminating process produces excellent stiffness to weight ratio, superior damping qualities
• 19mm BALANCED DRIVE MYLAR TWEETER - Excellent reproduction of high frequencies
• POLYMIDE VOICE COIL FORMER - High temperature light-weight voice coil structure for increased sensitivity
• TRIPLE-LAYER UV TREATED FOAM SURROUND - Premium design for excellent sensitivity and long term reliability
• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment
Advertisement
Table of Contents
Related Manuals for Phoenix Gold RX4CX
Summary of Contents for Phoenix Gold RX4CX
- Page 1 Coaxial loudSpeaker Manual Manuel de Coaxial Models: RX4CX, RX46CX, RX5CX RX57CX, RX65CX, RX69CX Features: • LAMINATE-TREATED PAPER CONE - Advanced laminating process produces excellent stiffness to weight ratio, superior damping qualities • 19mm BALANCED DRIVE MYLAR TWEETER - Excellent reproduction of high frequencies • POLYMIDE VOICE COIL FORMER - High temperature light-weight voice coil structure for increased sensitivity • TRIPLE-LAYER UV TREATED FOAM SURROUND - Premium design for excellent sensitivity and long term reliability • RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment...
- Page 2 Figure 2 Mounting the speaker in a custom application. Figure 1 Mounting the speaker in a factory location. SPECIFICATIONS: Due to continual product improvement, all specifications subject to change without notice. RX4CX RX46CX RX5CX RX57CX RX65CX RX69CX RMS Power Handling (watts) Peak Power Handling (watts) 100W 100W 120W Impedance (ohms) Cut Out Dimension (mm) / in. (93) 3.7 (143 X 88) 5.6 X 3.5 (120) 4.75 (188 X 131) 7.4 X 5.2 (144) 5.7 (221 X 154) 8.7 X 6.1 Mounting Depth (mm) / in. (50) 2.0 (51.5) 2.1 (55) 2.2 (71) 2.8 (64) 2.5 (76) 3.0 © 2013 Phoenix Gold • www.phoenixgold.com...
- Page 3 Coaxial Speaker Owner’s Manual Pour Les Modele: RX4CX, RX46CX, RX5CX, RX57CX, RX65CX, RX69CX INSTALLATION DE BASE La sélection de l’emplacement de vos nouveaux haut-parleurs coaxiaux RX INSTALLATION DU HAUT PARLEUR SANS GRILLES peut être aussi facile que l’utilisation des emplacements de fabrication Phoenix Gold a fourni un joint statique de montage en mousse. Lors de ou peut nécessiter la création d’un nouvel emplacement. L’emplacement le l’installation de vos nouveaux haut-parleurs coaxiaux dans une usine, plus courant est dans les portes, le tableau de bord ou à l’arrière du pont. assurez-vous d’utiliser les joints statiques de montage en mousse comme le Consultez votre concessionnaire Phoenix Gold pour un emplacement de montre la figure 1. Pour les haut-parleurs montés à l’envers, placez le joint en montage supplémentaire et de l’assistance. mousse en face du haut-parleur. Ceci assurera un joint étanche à l’air pour vos haut-parleurs RX. INSTALLATION DES HAUT-PARLEURS PORTES / PLAGE ARRIÈRE INSTALLATION DU HAUT PARLEUR AVEC GRILLES 1. D e nombreux véhicules ont déjà des emplacements d’usine (Figure 1)
- Page 4 Phoenix Gold A Division of AAMP of America™ 13190 56th Court Clearwater, Florida 33760 P: 888-228-5560 info@phoenixgold.com www.phoenixgold.com © 2013 AAMP of Florida, Inc Designed and Engineered in the USA LIMITED WARRANTY Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse, product modification or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear and tear is not covered under warranty. INTERNATIONAL WARRANTIES: Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by Phoenix Gold. Consumers needing service or warranty information for these products must contact that country’s reseller for information.
