Summary of Contents for Tactacam Reveal XB SK
- Page 1 INSTRUCTION MANUAL REVEALCELLCAM.COM...
- Page 2 D O W N L O A D T H E TACTACAM REVEAL APP V I S I T Y O U R A P P S T O R E T O D O W N L O A D...
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION Front View Bottom View of Camera Internal and Side View of Camera QUICK START What is in the Box? Setting up the Camera Downloading the App Adding Camera to the Web Portal or App SETTINGS &... -
Page 4: Introduction
INTRODUCTION Lens XB Antenna/SK has Additional on right IR LEDs Camera Working Status Indicator (Red) Device Status Indicator Light (Green/Blue) SD Card Indicator (Red/Green) SIM Slot (DO NOT REMOVE) Power Switch (ON/SETUP/OFF) PIR Motion Sensor WiFi Indicator Light (Blue) Microphone Battery Level Indicator 4G Signal Indicator SD Card Slot... -
Page 5: Quick Start
WHAT YOU WILL NEED • (1) Trail Camera • SD Card - Class 10, U3, 16GB-32GB • (1) Instruction Manual • Recommended Brands: Tactacam, • (1) Mounting Strap Lexar, SanDisk (Other brands of lower end SD cards are • (1) Antenna - XB=1 SK=2 incompatible with the Reveal X and will yield •... -
Page 6: Setting Up The Camera
2. Install a Class 10 U3 SD card (16GB or 32GB). • Recommended brands are: SanDisk, Lexar and Tactacam 3. XB = Install 12 AA batteries. • To eject the battery tray or SK-Lipo Pack, press the EJECT button on the Reveal. If install AA batteries correctly orientat + and - on the front and back of the tray. -
Page 7: Downloading The App
• Default camera WiFi SSID is Reveal_**** • Default camera WiFi password is Reveal2021 DOWNLOADING THE APP In your Apple or Google Play Store, download the Tactacam Reveal app and sign in using the same email and password you created on the website. -
Page 8: Adding Camera To The Web Portal Or App
QUICK START GUIDE SET UP CAMERA THROUGH WEB PORTAL If this is your first Reveal that you are activating, please visit the Reveal Web Portal at https://account.revealcellcam.com/activation to set up your account. You can also access the Web Portal directly from your app, by clicking My Reveal on this screen in the app: ADD CAMERA TO THE APP 1. - Page 9 QUICK START GUIDE ADD CAMERA TO THE APP (CONTINUED) 7. You can automatically change and apply the camera settings when your phone is connected to the camera’s WiFi. This will not work unless you are next to the camera. • You can also remotely change the camera settings from the App, it will take up to 24 hours for settings to be applied.
- Page 10 START USING THE REVEAL X SENDING A TEST PICTURE (CONTINUED) • When the test picture sends successfully, the status light will turn green. • If the status light turns red there may have been an issue trying to send the test photo. This is usually caused by signal strength.
-
Page 11: Settings & Specifications
SETTINGS / SPECIFICATIONS Camera Mode Photo; Photo+Video Day/Night Mode Daytime: Color, Nighttime: B+W IR Range 80+ Feet PIR Angle Flash No Glow IR Technology effectively eliminates all visible flash Operating Keys (2) 1x Power slide switch; 1x Test button Lens F=6mm;... - Page 12 SETTINGS / SPECIFICATIONS Battery XB = 12xAA Cartridge SK = Rechargeable lithium pack SK = Solar Panel attachment Optional external power source (12V external battery pack or solar panel) - Barrel plug reducer size 4x1.7mm External DC 12V-2A Transfer Picture via 4G High, detailed thumbnail images sent to app (Additional data charges may apply) Request HD Photo and Video...
-
Page 13: Best Practices
BEST PRACTICES MOTION SENSORS (PIR SENSORS) Motion sensors (PIR sensors) are actually heat and motion sensors. This is why on a hot and windy day, people get false triggers. People and animals are not the only objects that will trigger your camera; vegetation and precipitation can act as a moving target as well. - Page 14 60% of their useful life. 3. Expected picture count with the proper batteries (in greater than freezing temps) are: • Lithium: 4000+ pictures • Alkaline: 2500+ pictures 4. Always good and beneficial to pair a good battery with the Tactacam Lithium Solar Panel.
-
Page 15: Camera Stops Taking Images Or Won't Take Images
BEST PRACTICES CAMERA STOPS TAKING IMAGES OR WON’T TAKE IMAGES 1. Please make sure that the SD card is not full. If the SD card is full, the camera will stop taking images. Users can turn on SD Loop to avoid such problems. -
Page 16: Product Care
PRODUCT CARE INTERNAL CONDENSATION ON LENS The Reveal is IP66 rated waterproof. This means the camera is water resistant against powerful jets. The only way the Reveal can get condensation in or behind the lens is if the antenna is not screwed in all the way, or if there is dirt or debris on the seal. -
Page 17: Warranty
HOW LONG DOES THIS COVERAGE LAST? 1. One year from the date of purchase. 2. Be sure to register your Reveal under warranty at www.tactacam.com/warranty WHAT IS COVERED? 1. This limited warranty covers: manufacturer defects in materials and workmanship including but not limited to: •... - Page 18 FCC REGULATIONS Federal Communications Commission - Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the Federal Communications Commission rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 19 DO NOT RETURN THIS PRODUCT TO YOUR RETAILER PLEASE CALL 218-282-5650 EMAIL SUPPORT@REVEALCELLCAM.COM For any warranty issues or questions on how to film your hunts with Tactacam. 110 N Sunset Blvd, Caledonia, MN 55921 www.revealcellcam.com...
