Summary of Contents for Tecno T473
- Page 1 Mobile Explode picture Item Descripition Item Descripition LCD Lens Front Housing Front Camera PCBA...
- Page 2 CAM Frame Rear Housing CAM Lens Screw Battery Cover Battery Label Back CAM Mot coin Fraglle Label IMEI Label Water-proof Label Done Main key Label...
- Page 3 Foreword Valuable mobile phone user, thank you for choosing our mobile phone! Our mobile phones reply to the People's Republic of China communication industry standards European standards and are approved for GSM networks. Your phone may be used internationally with various networks depending on your roaming arrangements with your service provider.
-
Page 4: Quick Start
Quick start Install SIM card This phone supports two GSM SIM cards. Find SIM card’s groove in the back of the phone and slide it completely there. During installation, please make sure insert the SIM card into slot completely and pay attention to slot direction. -
Page 5: Call Function
Call function Dialing 1. Direct dial In standby mode, press the corresponding numeric keys to enter the phone number that you want to dial, including necessary area codes. Short press the right soft key to delete one character, and long press to delete all inputs, if only one SIM card is inserted, press the dial/receive key to dial, if two SIM cards are inserted, the phone displays select SIM card page, if you select SIM1 then use SIM1 to... - Page 6 the network operation company. Receiving calls When there is an incoming call, the phone will give corresponding alert, if your network supports caller ID, the screen will display caller’s name or number (depending on whether there is information of the caller in your phonebook).
-
Page 7: Menu Functions
Menu functions Contacts You can use the phone's contacts feature to save the contact name, number. The phone can save contacts on the phonebook, the number of contacts that can be stored in a SIM card varies according to their capacity. Enter the contacts screen, you can add new contact, view contacts list and select the contacts to call or other operations. - Page 8 outbox, the operation is the same with inbox. Sent messages If SMS is sent successfully, then it will be stored in the sent messages box. But automatically save messages need to select, other operation is the same with inbox. SMS Settings SIM settings: you can choose either of modes, custom different parameters, including set short message center number, set delivery report, reply path, voicemail server.
- Page 9 Settings Phone settings Time and date: in this function, you can choose menu to set the current time and date in idle screen, include set home city, set time/date and format etc. Language: in this function, you can choose the language provided by the phone.
- Page 10 the PIN, PIN2. But the original password is required to support your network operator. Phone security: you can on or off the phone password, phone password on or off are required to enter the correct password. Once opened this feature, the phone will prompt you to enter password, when turned on every time.
- Page 11 photo, press the right soft key to return, press the left soft key to get access to the camera settings, you can set scene mode, image size, white balance and more operations. After taking pictures, press the back button to return to camera preview screen, press the left soft key to enter options, can take pictures to send and delete.
- Page 12 start/pause the current video, press the left/right navigation key to switch previous/next video, Long press the left/right navigation key to pull the progress bar forward or backward; press “1” key or the up navigation key to switch full screen, press the */# key to adjust the volume, press the down navigation key to stop playing.
- Page 13 communications and Internet application platform that enables you to get more information by phone and e-commerce and other Internet information resources application. Files In document management, you can open files in the phone or memory card, into the option, you can open the file or folder, create new folder, rename, delete files etc.
- Page 14 Alarm You can use the phone as alarm clock, this feature allows you to set time, make the phone ring or vibrate to remind events. Calculator To get access to the calculator, the calculator interface: Press 0 - 9 numeric keys to enter the number to be calculated, press the navigation key to select the location on the screen corresponding to add, subtract, multiply and divide symbols.
-
Page 15: Input Methods
Input methods This phone provides diversified input modes for you, when you are editing SMS and adding contacts on the phonebook. Use the # key to switch between different input methods. When editing the key controls: The right soft key: press to clear one character, long press to clear all. -
Page 16: Fcc Caution
FCC Caution Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. - Page 17 The SAR limit of USA (FCC) is 1.6 W/kg averaged over gram tissue. Device types:T473(FCCID:2ADYY-T473) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 1.33 W/kg and when properly worn on the body is 1.37 W/kg.
- Page 18 antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.
