- Page 1 WOODEN CABINET INFRARED HEATER model no. 043-5997-6 Toll-free: 1-866-827-4985 IMPORTANT: Please read this manual carefully Instruction Manual before running this heater and save it for reference.
- Page 2 043-5997-6 | contact us: 1-866-827-4985 Packaging Contents Specifications Product Diagram Control Panel Remote Control Operation Cleaning and Maintenance Safety Features Important Safeguards Warranty...
- Page 3 Infrared Heater 2. Remote Control Instruction Manual...
- Page 4 043-5997-6 | contact us: 1-866-827-4985 Model 043-5997-6 Voltage 120 V AC / 12.5 A Frequency 60 Hz Settings High 1500 W, Low 750 W, ECO KNOW YOUR INFRARED HEATER Before use of this product, familiarize yourself with all operating...
- Page 5 Remote Control Air Outlet Control Panel Swivel Castor Air Intake Cord Clamps Master Power Switch...
- Page 6 043-5997-6 | contact us: 1-866-827-4985 Signal Receiving Window Timer Indicator Light Digital Display Timer Button Power Indicator Light °C/°F Button ON/OFF Button Celsius Indicator Light Mode Button Fahrenheit Indicator Light High Power Mode Control Panel Lock Button Indicator Light...
- Page 7 Signal-Receiving Window For receiving remote control signal. Digital Display Indicates set room temperature or time value of the timer. Power Indicator Light Indicates when the unit is connected to a power supply and rear master power switch is on. ON/OFF Button For power on or off.
- Page 8 043-5997-6 | contact us: 1-866-827-4985 ON/OFF Button Mode Button Temperature Up Button Temperature Down Button Timer Button Power Button Used for power on or power off. Mode Button Used for mode selection. Temperature Up Button To increase set temperature.
- Page 9 PREPARATION Place the heater on a firm, level surface, plug into a grounded, 120 V (60 Hz) power outlet and turn on the power switch on PULL the rear of the unit. Only operate heater in upright position with swivel castors attached.
- Page 10 043-5997-6 | contact us: 1-866-827-4985 STARTING AND SELECTING WORKING MODE High Mode uses 1500 W; Low Mode uses With master power switch at the rear 750 W. ECO mode is an economic energy- of the unit on, turn the heater on by saving function.
- Page 11 Set temperature indication varies from When Fahrenheit indicator light is on, 59°F to 86°F, or from 15°C to 30°C. digital display shows Fahrenheit value. Once you have chosen the desired temperature, the heater will remain on When Celsius indicator light is on, digital until the room temperature increases to display shows Celsius value.
- Page 12 043-5997-6 | contact us: 1-866-827-4985 SETTING TIMER POWER-OFF SETTING TIMER POWER-ON After starting the unit, press the timer Under power-off mode, press the timer button on the control panel. button on the control panel. REMOTE REMOTE CONTROL CONTROL...
- Page 13 SETTING ELECTRO-LOCK Press LOCK button on control panel for 3 seconds. Locking is confirmed when a tone is heard. When locked, control panel and remote control will not function. A tone will be heard when buttons are pressed but they will not function.
- Page 14 Turn off the power switch in the rear Reassemble filter and then attach to of the unit. heater. WARNING: Do not use heater Unplug the unit and let it cool completely. without filter assembly in place or To keep the heater clean, the outer with a filter that is not completely dry.
- Page 15 STORAGE Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the original packaging to repack the unit. TROUBLESHOOTING If the heater or power supply unit will not operate, check the following before seeking repair or service: Check if the power cord is plugged into an electrical outlet.
- Page 16 043-5997-6 | contact us: 1-866-827-4985 SAFETY TIP-OVER PROTECTION FEATURE This heater is equipped with a safety tip-over protection feature. Once the heater is tipped over, an internal switch will automatically shut the heater off. Once the heater is restored an upright position, the heater will reset. To continue operation, turn on the heater using the supplied remote control or the control panel on the heater.
- Page 17 10. DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or similar coverings. Arrange cord away from traffic areas and where it will not be tripped over. 11. DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater.
- Page 18 LIMITED 1-YEAR WARRANTY This product carries a one (1) year warranty against defects in workmanship and materials. Noma Canada agrees to replace a defective product, within the stated warranty period, when returned to the place of purchase with proof of purchase.
