Occasionally CD-R and CD-RW discs written by a CD-R/RW drive cannot be read by other
CD drives. These unreadable discs may need to be read using the CD-R/RW drive they
were created with. The disc written using the CD-R/RW drive might not be readable by
CD-ROMs other than Multi-read compatible (UDF compatible) CD-ROMs.
Multiread compatible (UDF compatible) CD-ROMs are CD-ROMs that can read low
reflectance and support Packet Write.
❏ Please note: Certain software (i.e. particularly those including Video playback) may require
a considerably increased specification PC to give acceptable results. While this Blu-ray
Disc Rewriter can read DVD-video or BD-MV(BD-ROM) discs, decoding them to
display on your pc's monitor requires separate MPEG, H.264 or VC-1 decoding that is done
by separate hardware (either an MPEG, H.264 or VC-1 decoder card or MPEG, H.264 or
VC-1 decoding done by your video card), or separate software that you install to do
MPEG, H.264 or VC-1 decoding. For further details, refer to the documentation that comes
with MPEG, H.264 or VC-1 software.

Location and Function of Controls

Front Panel
1
2
1. Disc Tray
2. Drive activity indicators
The LED used to indicate the operation of
Blu-ray Disc Rewriter.
3. Emergency Eject Hole
4. Eject Button
Rear Panel
3
4
1. SATA Power Connector (15 pin)
2. SATA Data Connector (7 pin)
4
1 2
