Motivo Tour Owner's Manual

Hide thumbs Also See for Tour:
Table of Contents

Advertisement

Quick Links

Download this manual
Tour Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tour and is the answer not in the manual?

Questions and answers

Related Manuals for Motivo Tour

Summary of Contents for Motivo Tour

  • Page 1 Tour Owner’s Manual...
  • Page 3 We are very pleased you have chosen the Tour and invite you to connect with us and other Tour users at www.facebook.com/motivolife. The following owner’s manual provides details on how to safely and effectively use your Motivo Tour and all its integrated features.

  • Page 4: Warning And Safety Instructions

    Tour. The tray weight limit is 8 lb (3.6 kg) and the storage compartment is 10 lb (4.5 kg). The seat weight limit is 300 lb (136 kg).
  • Page 5 • DO NOT hang anything other than a cane or Motivo certified accessories from your Tour. Hanging items from the Tour can make it unstable and cause it to tip. To accommodate a cane, there are special notches designed into the top of the Tour.

  • Page 6: Product Description

    Product Description Right Handle Cup Holders Flip-Out Tray Brake Levers Cane Hook Backrest Stow-Away Seat Right Side Latch Storage Door Seat Cushion Seat Platform Right Side Handle Brake Shoe Height Adjustment Knobs RIGHT SIDE VIEW INSIDE VIEW...
  • Page 7 Left Handle Cane Hook Left Side Latch Seat Support Bar Carry Handle Left Side Brake Shoe LEFT SIDE VIEW FOLDED VIEW...
  • Page 8 Unfolding Your Tour LOCK 1. Pull the black strap to release the 2. Using the LEFT handle, FULLY Velcro style closure. unfold the LEFT side. Press down ® on the LEFT side latch lever until it locks. WARNING: Pinch points exist between the front and side panels.
  • Page 9 LOCK 3. Using the RIGHT handle, FULLY 4. Squeeze handles towards each unfold the RIGHT side. Press other to make certain latches are down on the RIGHT side latch FULLY engaged before use. If either lever until it locks. side folds in, repeat steps 2-4.
  • Page 10 How to Operate the Brakes 1. Squeeze both hand brake levers 2. Push down FULLY on each brake to slow the Tour down or stop the lever until both click to engage the Tour temporarily. parking brakes. Verify rear wheels do not rotate before sitting.
  • Page 11 Adjusting the Brake Tension 1. Standing inside the Tour, loosen the locking nut by turning it clockwise. 2. For more tension and to move the brake shoe closer to the rear wheel, turn the knurled cap clockwise. For less tension and to move the brake shoe away from the rear wheel, turn the knurled cap counterclockwise.

  • Page 12: Adjusting The Handle Height

    Adjusting the Handle Height 1. To keep the Tour from rolling, set 2. Start by unscrewing the knob at parking brakes (p. 8) and complete the base of the handle turning it steps 2-3 for each handle. counterclockwise. Refer to Handle Height Guide (p.
  • Page 13 Above measurements are from handle hole aligns with the side the ground to the top of the grip. panel hole. To secure, insert ALWAYS consult your healthcare and FULLY tighten knob turning professional to determine proper clockwise. adjustment and usage of the Tour.
  • Page 14 Using & Storing the Seat 1. Activate both parking brakes 2. Pull the seat straight up until it FULLY before using the seat (p. stops and both lower clips snap 8). Make sure tray is folded and onto the seat support bar. Rotate storage door is closed (pp.
  • Page 15 SECURED CLIPS CATCH 3. Align and place seat end securely 4. To store, lift seat and rotate until on the LEFT side seat platform. vertical. Then, slide seat down until ONLY use seat when secured both upper clips snap onto the seat on the LEFT side seat platform support bar and the bottom edge and sits parallel to the ground.
  • Page 16 Unfolding & Folding the Tray 1. To unfold, pull up on the top half of 2. To fold, rotate the tray up and the tray and rotate open. The tray press to fasten the magnetic weight limit is 8 lb (3.6 kg). closure.
  • Page 17 Opening & Closing the Storage Compar tment 1. Using hand opening, pull to open. 2. To close, push up on the storage Compartment weight limit is 10 door until it latches. lb (4.5 kg). DO NOT put more than 5 lb (2.3 kg) on the storage door when open or use as a seat.
  • Page 18 UNLOCK UNLOCK UNLOCK 2. Fold in the RIGHT side. To close 1. Before folding, turn the Tour slightly to rotate the front wheels securely, always fold the RIGHT to one side. Then, release the side in FIRST. Next, release the...
  • Page 19 Transpor ting Your Tour 3. Fold the LEFT side in and secure To transport, fold your Tour (p. 16) the folded Tour with the Velcro and with the folded sides facing you style closure. pick up using the carrying handle inside the RIGHT hinge.
  • Page 20 • Regular inspection of parts including hardware, brackets, and plastics, for deformation, corrosion, breakage, wear or compression is recommended. • Regular cleaning of the Tour is recommended. Wipe all surfaces, including cushions, with a damp cloth and wipe surfaces dry before use. DO NOT use harsh chemicals or solvents.

  • Page 21: Lifetime Limited Warranty

    The exclusive remedy for the above warranty shall be repair or replacement of defective parts within the warranty period. If within such warranty period the Tour shall be proven to be defective, it shall be repaired or replaced, at Motivo’s option, with refurbished or new parts. This warranty does not include any labor or shipping charges incurred in replacement part installation or repair of the Tour.

  • Page 22: Exclusions And Limitations

    The warranty does not cover normal wear and tear, improper maintenance, or installation of parts or accessories not originally intended or compatible with the Motivo Tour. The warranty does not apply to damage or failure due to accident, abuse, corrosion, discoloration of plastic, or neglect. Motivo, Inc.
  • Page 24 Motivo, Inc. 16227 W Ryerson Rd New Berlin, WI 53151 (414) 235-9409 www.motivolife.com @motivolife Facebook.com /motivolife Made in the USA ® Copyright ©2018 Motivo . All rights reserved.
