  • Page 1 Tour Owner’s Manual...
  • Page 2 We are very pleased you have chosen the Tour and invite you to connect with us and other Tour users at www.facebook.com/motivolife. The following owner’s manual provides details on how to safely and effectively use your Tour and all its integrated features.

  • Page 3: Warning And Safety Instructions

    Tour. The tray weight limit is 8 lb (3.6 kg) and the storage compartment is 10 lb (4.5 kg). The seat weight limit is 300 lb (136 kg).
  • Page 4 • DO NOT hang anything other than a cane or Motivo certified accessories from your Tour. Hanging items from the Tour can make it unstable and cause it to tip. To accommodate a cane, there are special notches designed into the top of the Tour.
  • Page 5 Unfolding Your Tour LOCK 1. Pull the black strap to release the 2. Using the RIGHT handle, FULLY Velcro style closure. unfold the RIGHT side. Press down ® on the RIGHT side lever until it locks. WARNING: Pinch points exist between the front and side panels.
  • Page 6 LOCK 3. Using the LEFT handle, FULLY 4. Squeeze handles towards each unfold the LEFT side. Press down other to make certain latches on the LEFT side latch lever until are FULLY engaged before use. If it locks. panels fold in, repeat steps 2-4.
  • Page 7 How to Operate the Brakes 1. Squeeze both hand brake levers 2. Pull down FULLY on each parking to slow the Tour down or stop the brake strap to engage the parking Tour temporarily. brakes. Verify rear wheels do not...
  • Page 8 Drag Brake Feature The brakes can also be used as a drag brake, meaning the brakes are partially engaged to slow the rotation of the wheels, such as when going down a ramp or incline. 1. To activate, partially pull down on each of the brake straps to the desired resistance on the wheels.

  • Page 9: Adjusting The Handle Height

    Adjusting the Handle Height 1. To keep the Tour from rolling, set 2. Refer to Height Guide (pg. 9) to parking brakes (pg. 6). Complete determine height setting. Slide the steps 1-3 for each handle. Start by handle up until the silver rivet aligns releasing the handle locking clamp with the selected mark.
  • Page 10 Apply downward the ground to the top of the grip. pressure on the handle, also ALWAYS consult your healthcare attempt to rotate. If handle is not professional to determine proper locked, repeat steps 1-3. adjustment and usage of the Tour.
  • Page 11 Using & Storing the Seat 1. Activate both parking brakes 2. Pull the seat straight up and FULLY FULLY before using the seat. Make out of its storage compartment. sure tray is folded and storage When it stops, rotate down. door is closed (pg.
  • Page 12 SECURED UNSECURED 3. Align the locking post on the LEFT 4. To store, lift seat up off of the side ledge with the corresponding locking post, rotate until straight receiver on the seat. ONLY use up and down, then slide seat back seat when secured on the into its storage compartment.
  • Page 13 Unfolding & Folding the Tray 1. To unfold, pull up on the top half of 2. To fold, rotate the tray up and the tray and rotate open. The tray press to fasten the Velcro style weight limit is 8 lb (3.6 kg). closure. Cup holder may be removed for cleaning.
  • Page 14 Opening & Closing the Storage Compar tment 1. Using the hand opening, pull to 2. To close, push up on the storage open. Compartment weight limit door until it latches. is 10 lb (4.5 kg). DO NOT put more than 5 lb (2.3 kg) on the storage door when open or use as a seat.
  • Page 15 Folding Your Tour UNLOCK UNLOCK UNLOCK 2. Fold in the left side. To close 1. Before folding, turn the Tour slightly to rotate the front wheels securely, always fold the LEFT to one side. Then, release the side in FIRST. Next, release the LEFT side by pulling up on the RIGHT side by pulling up on the LEFT side lever to unlock.
  • Page 16 Transpor ting Your Tour 3. Fold the RIGHT side in and secure To transport, fold the Tour, secure the folded Tour with the Velcro closure, and with folded sides facing style closure. you pick up using the carrying handle inside the RIGHT hinge.
  • Page 17 Adjusting the Brake Tension 1. Standing inside the Tour, loosen the locking nut by turning it clockwise. 2. For more tension and to move the brake shoe closer to the rear wheel, turn the knurled cap clockwise. For less tension and to move the brake shoe away from the rear wheel, turn the knurled cap counterclockwise.
  • Page 18 Repeat corresponding shape on the Tour. steps 1-2 for each side graphic. TIP: Evenly mist Tour surface with TIP: Use a credit card to smooth as glass cleaner before applying to allow you go and push any air bubbles out temporary repositioning.
  • Page 19 • Regular inspection of parts including hardware, brackets, and plastics, for deformation, corrosion, breakage, wear or compression is recommended. • Regular cleaning of the Tour is recommended. Wipe all surfaces, including cushions, with a damp cloth and wipe surfaces dry before use. DO NOT use harsh chemicals or solvents.

  • Page 20: Lifetime Limited Warranty

    The exclusive remedy for the above warranty shall be repair or replacement of defective parts within the warranty period. If within such warranty period the Tour shall be proven to be defective, it shall be repaired or replaced, at Motivo’s option, with refurbished or new parts. This warranty does not include any labor or shipping charges incurred in replacement part installation or repair of the Tour.

  • Page 21: Exclusions And Limitations

    The warranty does not cover normal wear and tear, improper maintenance, or installation of parts or accessories not originally intended or compatible with the Motivo Tour. The warranty does not apply to damage or failure due to accident, abuse, corrosion, discoloration of plastic, or neglect. Motivo, Inc. shall not be responsible for incidental or consequential damages.
  • Page 22 Motivo, Inc. 16227 W Ryerson Rd New Berlin, WI 53151 (414) 235-9409 www.motivolife.com @motivolife Facebook.com /motivolife Made in the USA ® Copyright ©2016 Motivo . All rights reserved.
