Summary of Contents for Ayrton AYD-12
- Page 1 AYD-12 Dehumidifier Operation manual...
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS Do not install and use your dehumidifier before completely reading these instruction. This will help you optimize the operation of your dehumidifier. The following advice and instructions should be followed closely: 1. Your unit must always be used in an upright position because it contains cooling agent. 2. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, electric shockor personal injury. SAFETY PRECAUTIONS When using this dehumidifier, always follow basic safety precautions, including the following: Always operate the product from a power source of ... -
Page 4: About The Controls On The Dehumidifier
ABOUT THE CONTROLS ON THE DEHUMIDIFIER High and Low fan indicator lights. Bucket full light indicates bucket needs to be emptied or it is not in the proper place. 4 hour or 2 hour Continuous operation indicator lights on indicator light. Power On indicator light Clean the Filter indicator light... -
Page 5: Using The Dehumidifier
USING THE DEHUMIDIFIER When first using the dehumidifier, operate the unit continuously 24 hours. How the Dehumidifier Operates Automatic Defrost Moist, humid air is drawn over a cold refrigerated When frost builds up on the evaporator coils, the dehumidifying coil. Moisture in the air condenses on compressor will cycle off and the fan will continue to this coil and drains into a bucket (or through a hose run until the frost disappears. -
Page 6: Removing Collected Water
USING THE DEHUMIDIFIER Always make sure the water bucket is locked into place on the dehumidifier. Removing Collected Water There are 2 ways to remove collected water: 1. Use the bucket. When the bucket is removed, the 2) Screw the drain connector to (included in the unit will shut off. -
Page 7: Care And Cleaning Of The Dehumidifier
CARE AND CLEANING OF THE DEHUMIDIFIER Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. Grille and Case To clean the case: To clean the front grille: Use water and a mild detergent. Do not use bleach or Use a vacuum attachment or brush. -
Page 8: Troubleshooting
TROUBLESHOOTING Problem Possible Causes What To Do Make sure the dehumidifier’s plug is pushed Dehumidifier does not The dehumidifier is unplugged. start. completely into the outlet. Dehumidifier has reached its The dehumidifier automatically turns off when either preset level or bucket is full. condition occurs. -
Page 9: Long Term Storage
Make sure there is no water left in the water tank and take off the draining hose. Take off the power cord and plug and warp them well. Clean the unit and packed it well to keep it from dust. TECHNICAL SPECIFICATION Model AYD-12 Rated Voltage 220–240 V~ Rated Frequency 50 Hz Rated Power 230 W (max. - Page 10 Producer: SINCLAIR CORPORATION Ltd., 1-4 Argyll St., London W1F 7LD, UK, www.sinclair-world.com This product was manufactured in China (Made in China). REPRESENTATIVE, TECHNICAL SUPPORT SINCLAIR Global Group s.r.o. Purkyňova 45 612 00 Brno Czech Republic Tel.: +420 541 590 140 Fax: +420 541 590 124 www.ayrton-world.com info@ayrton-world.com...
