  • Page 1 HANDHELD COMPUTER DA05 Pocket PC Quick Start Guide...
  • Page 2 Copyright © 2007 All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, or computer language, in any form, or by any means, electronic, mechanical, magnetic, optical, chemical, or other, without the prior written permission of the manufacturer.
  • Page 3 Microsoft, Windows CE, Pocket PC, and Windows Mobile are registered trademarks of Microsoft Corp. Intel, Bulverde are the registered trademarks of Intel Corp. All product and company names are trademarks or registered trademarks of their respective holders.
  • Page 4 EMC and Safety Notice Federal Communications Commission Radio Frequency Interference Statement This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 6 1. Turn OFF the unit and unplug the AC adapter from the outlet to see if the interference disappears. 2. Connect the AC adapter to the outlet in another room and check if the interference still exists. 3. Use an outlet that is far away from the interfered appliance. 4.
  • Page 7 EN55022 +A2:2003 Class B EMI Conduction and Radiation EN61000-3-2 Harmonics EN61000-3-3 +A1:2001 Flicker (Voltage fluctuation) EN55024 EMS EN61000-4-2 +A2:2001 ESD EN61000-4-3 +A1:2002 RS EN61000-4-4 +A2:2001 EFT EN61000-4-5 +A1:2001 Surge EN61000-4-6 +A1:2001 CS EN61000-4-8 Power-Frequency Magnetic Field EN61000-4-11 +A1:2001 Voltage Dips and Voltage Interruptions LVD EN60950-1 :2001 ETSI EN301 489-01 V1.4.1 EMC Standards for Radio Equipment ETSI EN 301 489-17 1.2.1 EMC Standards for 2.4GHz Wideband Transmission...
  • Page 8 UL, TÜV AC Adapter (EN60950 LVD is included in TÜV) E-Mark Registered e13 Material Safety and Recycling Notice All materials used in the construction of this unit are recyclable or environmentally friendly. No mercury, cadmium, CFC or related materials were used in the manufacturing process or inside the product.

  • Page 9: Table Of Contents

    CONTENTS GETTING STARTED....................1 ......................1 NPACKING ......................2 UICK HECK ............... 3 ONTROLS NDICATORS ORTS ............10 PERATING NVIRONMENT AND UGGEDNESS COMPONENTS AND FUNCTIONS ..............11 ......................11 ADAPTER ....................... 11 ATTERY ....................12 HARGE ATTERY ...................... 13 ATTERY OPTIONAL DEVICES...................
  • Page 10 .......................20 ..................20 ALIBRATE OUCH CREEN ....................20 DJUST OLUME ..............20 UTTON UNCTIONS ......................21 ODAY CREEN ......................21 IND A ....................21 EMOVE ROGRAMS ..................21 ANAGE ERTIFICATES ........................22 NPUT ........................22 ENUS ....................22 WNER NFORMATION ......................22 ASSWORD & N ..................22 OUNDS OTIFICATIONS ........................23 LOCK ........................23 EMORY ........................23 OWER...
  • Page 11 USING BLUETOOTH (OPTION) ................ 37 SPECIFICATIONS ....................59 CPU........................59 ........................ 59 EMORY ......................... 59 ISPLAY ...................... 59 OUCH CREEN ......................60 PORTS ............... 60 YSTEM IMENSIONS AND EIGHT AC A ......................60 DAPTER ....................... 61 ATTERY ................. 62 ATERIALS AND ECYCLING ..................

  • Page 13: Getting Started

    GETTING STARTED Unpacking The following components come with your handheld computer. If anything is missing or damaged please notify the dealer immediately. Handheld computer unit AC adapter AC power cord User's guide Companion CD Data sync cable (USB) Spare stylus(with tether)

  • Page 14: Quick Check

    Quick Check • Attach the AC adapter to AC outlet. The adapter LED indicates the power is ready. • Insert the battery and then plug in the adapter to handheld computer. Orange charge LED will light up till the battery is full charged. Charging time will be , It’s recommended the battery is full charged about 4 hours.

  • Page 15: Controls, Indicators, And Ports

    Controls, Indicators, and Ports Front:...
  • Page 16 Wireless ON/OFF (Flight or button 3) Turn ON/OFF the wireless device (Option: WiFi, Bluetooth, Phone, GPS) Please turn it OFF at locations with wireless control (hospital, onboard airplane, etc.) Button (User programmable)(Dial button in Phone edition) Button (User programmable) Navigator button [Left], [Right], [Up], [Down] 4 directions [Enter] at the center Button (User programmable)
  • Page 17 Rear: DB9 Connector Stylus...
  • Page 18 Reset Button Battery knob Battery Microphone Speaker (under hand strap) Phone receiver Left: Wireless device antenna USB client port Data sync with the computer.
  • Page 19 USB Host port For Keyboard, USB Flash storage. Kensington lock slot Right: Microphone/Earphone jack SD I/O slot (Secured Digital card and device) antenna (optional)
  • Page 20 Top: Serial port or GPS antenna...
  • Page 21 Bottom: DC jack PCMCIA slot One PCMCIA type II slot CF (Compact Flash card) will be available by PCMCIA-to-CF adapter Cradle docking connector Connection to cradle...

  • Page 22: Operating Environment And Ruggedness

    Operating Environment and Ruggedness A clean and moisture-free environment is preferred. If it is necessary to work in a hostile environment, please make sure all ports are well protected from dust, moisture, or water. Proper isolation from extreme hazardous exposure is recommended. The computer is designed with rugged features of vibration, shock, dust, and rain/water protection.

  • Page 23: Components And Functions

    COMPONENTS AND FUNCTIONS AC adapter When using the AC adapter: • Use a properly grounded AC outlet. • Use one AC outlet exclusively for the computer. Having other appliances on the same line may cause interference. • Use a power strip with built-in surge protection. The AC adapter automatically detects the AC line voltage (110V or 220V) and adjusts accordingly.

  • Page 24: Charge Battery

    • Shut down the computer when not to use for a longer time Battery Low When the battery is nearly exhausted, the computer prompts a window warning. Once the Battery Low warning occurs, please do either or all of the following: Save and close the files you are currently working on Plug in the AC adapter to recharge the battery Swap a charged battery...

  • Page 25: Swap Battery

    Swap Battery To swap the battery: Turn power OFF Turn the battery knob counterclockwise to loose the battery Remove battery from compartment Insert a new battery Press the battery down and turn battery knob clockwise to lock it Press power button to turn ON the computer...

  • Page 26: Optional Devices

    Optional Devices Cradle (optional) Cradle is the device for docking, port extension, and battery charging. AC adapter may attach directly to cradle and charges the computer battery as well as spare battery. There is a battery slot on the back of cradle to mount spare battery.
  • Page 27 Front: Right LAN/RJ45...
  • Page 28 Rear...
  • Page 29 Battery Lock Spare battery charger USB Client USB Host DC IN COM port Optional COM port Mount the cradle: Computer may dock either power is ON or OFF (recommend OFF) Open the rubber cap on the docking connector Align the computer with cradle docking connector Firmly push the computer down to engage the docking connector Turn rotary latch to fix the computer Remove from the cradle:...

  • Page 30: Pcmcia Slot

    Pull away the computer either power is ON or OFF Mount spare battery: (spare battery is optional) Perform the same procedure as mounting primary battery on computer. Cradle will charge computer and spare battery simultaneously. PCMCIA Slot The computer accepts one type-II PCMCIA card. Insert the card firmly into the slot and fix the rubber cover for water/dust protection.
  • Page 31 Note: If the computer is working with dust, moisture, or water, be sure to fix the SD rubber cap tightly with screws.

  • Page 32: Basic Operation

    BASIC OPERATION Get Help Tap Start Help Get the needed information from the list or the bundled CD. Calibrate Touch Screen Tap Start Settings System Screen Align Screen to calibrate. Adjust Volume Tap speaker icon on the top bar and adjust the volume level as desired. Set Your Own Button Functions Tap Start Settings...

  • Page 33: Today Screen

    Today Screen The today screen displays information of today’s appointments and status icons, etc. Tap the information listed on today screen to execute the associated program. Tap Start Today to enter Today screen. Find a File Tap Start Find In Find, enter the file name, word, or other information you want to search for, If you have looked for this item before, tap the Find arrow and select the item from the list.

  • Page 34: Input

    Input Tap Start Settings Personal Input Select the input method and option you want. Menus Tap Start Settings Personal Menus and select the items you want to appear on Start Menu. Owner Information Tap Start Settings Personal Owner Information and follow the descriptions.

  • Page 35: Clock

    Clock Tap Start Settings System Clock. Memory Tap Start Settings System Memory and follow the descriptions. The main tab displays the amount of memory the system has allocated to file and data storage versus the available memory. The storage card tab displays how much memory is available on a storage card that is inserted in your device.
  • Page 36 Press and Hold Key4 and use stylus to tape reset button (on the rear).System will enter Eboot mode. Press Key5 to format Storage. Use stylus to tape rest button(on the rear) to reboot System...

  • Page 38: Using Wireless Lan (Option)

    Using Wireless LAN (option) Connect to Internet Turn on the Wireless Signals. Tap “Start”->”Settings”-> “Connection” tab. Tap “Wireless Manager” and select “<WiFi>” item then select checkbox to “ON”. (Figure 1-1 & 1-2) Wireless function has been enabled. (Figure 1-3)
  • Page 39 To input network authentication keys. (Figure 1-4) If network keys are ok then you can see the Wireless works correctly. (Figure 1-5) Open Internet Explorer, now you can use Wireless function to connect to interne...
  • Page 40 Connect to Intranet Network: 2.1 Please refer to step 1.1 ~ step 1.3 2.2 Select “Work” option need to set the proxy later. (Figure 2-1). 2.3 if the connection needs network key, the screen will promptly pop up a Network key input Just type a correct network keys. (Figure 1-4)
  • Page 41 2.4 Tap “Start”->”Settings”-> “Connection” tab and tap “Connections”. (Figure 2- 2.5 Select “Set up my proxy server” to setup proxy and other relative settings etc. (Figure 2-3 & 2-4) 2.6 Tap “Start”->”File Explorer” , select “Menu”->”Open Path”->”New Path” , it will pop up a dialog to prompt you enter your intranet path.

  • Page 43: Using Gsm/Gprs (Option)

    Using GSM/GPRS (option)
  • Page 44 3. GSM Firstly, to unplug the battery from DA05 rear and put SIM card into SIM slot. Make sure the SIM card is connected correctly then put the battery back to DA05. (Figure 3-1) Tap “Start”->”Settings”-> “Connection” tab Tap “Wireless Manager” and select “<PHONE>” item then select checkbox to “ON”.
  • Page 46 GPRS Please refer to step 3.1 ~ step 3.4.
  • Page 47 Tap “Start”->”Settings”->”Connections” and select “Add a new modem connection” under “My ISP” item. (Figure 4-3) 4.3 select modem type to "Cellular Line(GPRS)", tap Next, then enter the Access Point Name(APN) ( Note: It is most important to enter this name, and the APN is different for each ISP provider).

  • Page 49: Using Bluetooth (Option)

    Using Bluetooth (option)
  • Page 50 1. Beam File function: Turn on bluetooth signals. Tap “Start”->”Settings”->”Connections”. (Figure 1-1) Tap Beam and make sure that the “Receive all incoming beams” option is checked. (Figure 1-2) Tap “Start”->”Program”->”File Explorer”, tap and hold the file name to be copied and then tap “Beam File” on the pop-up menu. (Figure 1-3) Then you will see discoverable devices like following screen and tap then send this file to target device.
  • Page 52 OBEX Profile : 2.1 Tap “Start”->”Settings”->”Connections”. (Figure 2-1)
  • Page 53 2.2 Tap BlueTooth and make sure that both “Turn on Bluetooth” and “Make this device visible to other devices” options are checked. ( Figure 2-2) 2.3 Execute IVT Soleil Bluetooth program from PC. (Figure 2-3) 2.4 Click Pocket_PC icon and click right mouse button then choice pairing option. 2.5 To input pairing password with connected device.(Note: pairing password must same as remote device)( Figure 2-3) 2.6 Meanwhile, device side will appear pairing password dialog as figure B2.4 and...
  • Page 58 FTP Profile : 3.1 Please refer to step 2.1 ~ step 2.6. 3.2 Tap highlight icon “FTP Service” from PC’s IVT Soleil program then transfor Naming card to device. (Figure 3-1) 3.3 Finally, drag target file from File Explorer and drop to “Remote share folder” then file transfer will be done.
  • Page 61 ActiveSync Profile : 4.1 Tap “Start”->”Settings”->”Connections”. (Figure 2-1) 4.2 Tap “BlueTooth” –> “Device”->”Add new device” to search PC bluetooth host devices. (Figure 4-1) 4.3 Tap “COM Ports” ->“New Outgoing Port” and tap target device like “ttt- fbggsz39grh” , tap “Next” and choice virtual com port. Here it assumed is “COM7”...
  • Page 63 A2DP Profile : 5.1 Tap “Start”->”Settings”->”Connections”. (Figure 2-1)
  • Page 64 5.2 Tap “BlueTooth” –> “Device”->”Add new device” to search Bluetooth A2DP device. (Figure 5-1) 5.3 To input the pairing password is “0000” and task bar will appear headset icon. 5.4 Now you could play music or video file and heard sound from connected device.
  • Page 65 Hand-Free Profile : 6.1 Tap “Start”->”Settings”->”Connections”. (Figure 2-1) 6.2 Tap “BlueTooth” –> “Device”->”Add new device” to search Hand-Free device. (Figure 5-1) 6.3 To input the pairing password is “0000” and task bar will appear headset icon. 6.4 Now you could press Hand-Free button from remote device and see phone’s dial-up dialog appear for your operate.
  • Page 67 SPP Profile : 7.1 Tap “Start”->”Settings”->”Connections”. (Figure 2-1) 7.2 Tap “BlueTooth” –> “Device”->”Add new device” to search SPP device. (Figure 7-1) 7.3 Tap “New Outgoing Port” to 7.4 To input the pairing password is “0000”. 7.5 Select a “Virtual Com Port” like “COM6” for your implemented. 7.5 Now you could use Bluetooth GPS device to receive GPS data.
  • Page 69 HID Profile : 8.1 Tap “Start”->”Settings”->”Connections” (Figure 2-1) 8.2 Tap “BlueTooth” –> “Device” tab and tap “Add new device” to search Bluetooth HID Mouse device. (Figure 8-1) 8.3 To input the pairing password is “0000”. 8.4 Now you could use Bluetooth HID Mouse to move mouse position and click focus something.

  • Page 71: Specifications

    SPECIFICATIONS Intel Bulverde PXA270 CPU speed 624MHz Memory 128MB 128MB Display Type: 4” Active TFT Transflective Color LCD Resolution: 480 x 640 pixels Color: Backlight: Touch Screen Type: Resistive...

  • Page 72: I/Oports

    Interface: Serial I/O ports USB 2.0 port USB client port Serial port Audio ports (Microphone/Earphone) PCMCIA slot (type II x 1) SD slot System Unit Dimensions and Weight Width: 90mm (W 3.5”) Depth: 150mm (H 5.9”) Height: 33mm (D 1.3”) Weight: 450g (15 oz.) AC Adapter...

  • Page 73: Battery

    Frequency: 50/60 Hz Output Voltage: DC 12V 3.75A Maximum Power: 45 Watts Dimension: 108mm (4.2” W) x 56mm (2.2” D) x 34mm (1.3” H) Weight: 270 g (9.5 oz.) Battery Type: Lithium Ion Capacity: 3.7V 3900mAH Dimension: 71mm (W 2.8”) x 64mm (D 2.5”) x 12.3mm (H 0.5”) Weight: 108 g (3.8 oz.)

  • Page 74: Materials And Recycling

    Materials and Recycling Materials of the computer are as follows: Cabinet: Aluminum alloy ADC-12 or A380, Magnesium alloy AZ91D, UL grade PC+ABS GE C6200 or TN-3813BW Bracket: Aluminum 5052 Steel with Nickel plating Stainless Steel S304 Cushion pad: Nature rubber PCB: FR-4, UL 94V0 Battery:...

  • Page 75: Environmental Ratings

    Environmental Ratings Temperature: DA05I: 0ºC ~ 45ºC (32ºF ~ 113ºF) operating -20ºC ~ 60ºC (-4ºF ~ 140ºF) storage DA05M: -20ºC ~ 50ºC (-4ºF ~ 140ºF) operating -40ºC ~ 70ºC (-40ºF ~ 158ºF) storage Humidity: 5 ~ 95% Non-condensing operating 95% maximum storage Altitude: 0 ~ 12,180 meters (0 ~ 40,000 feet) operating and storage...

  • Page 76: Maintenance / Service

    MAINTENANCE / SERVICE Cleaning Always turn OFF the power, unplug the power cord and remove the battery before cleaning. The exterior of the system and display may be wiped with a clean, soft, and lint-free cloth. If there is difficulty removing dirt, apply non-ammonia, non-alcohol based glass cleaner to the cloth and wipe.

  • Page 77: Rma Service

    • Remove the software suspected. RMA Service If troubleshooting is unsuccessful, please consult your dealer for service If it is necessary to send in the computer for repairs, please follow the dealer’s instructions for RMA# procedure. Shipping instructions: Use the original shipping container and packing materials, if possible. If the original packing materials are not available, wrap the equipment with soft material (e.g., PU/ PE form) then put the wrapped equipment into a hard cardboard shipping box.
  • Page 78 A DETAILED description of the problems you have encountered • A list of the hardware/software configuration, if applicable. • Clearly mark the outside of the shipping box with the RMA number. This will facilitate faster processing and avoid faulty return. Unless prior arrangements have been made, the customer is responsible for all shipping costs.
