  • Page 1 User Manual Handheld Computer roda ® Windows Mobile DA05+...
  • Page 2 DA05+ WM6 User Manual roda ————————————————————————————— Page 2 of 49 —————————————————————————————...
  • Page 3 DA05+ WM6 User Manual roda ————————————————————————————— roda computer GmbH Landstrasse 6 77839 Lichtenau/Baden Telefon: +49(0)7227/9579-0 Telefax: +49(0)7227/9579-20 roda Service Center Hüllhorst Bredenhop 20 32609 Hüllhorst Telefon: +49(0)5744/944-470 Telefax: +49(0)5744/944-475 Page 3 of 49 —————————————————————————————...
  • Page 4 (and not the manufacturer, its distributor, or its supplier) assumes the entire cost of all necessary servicing, repair and any incidental or consequential damages resulting from any software defects. Copyright © 2009 roda computer GmbH Lichtenau, September 2009 Author: Joachim Tschan Version History:...
  • Page 5 DA05+ WM6 User Manual roda ————————————————————————————— EMC and Safety Notice Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6 DA05+ WM6 User Manual roda ————————————————————————————— Standards Specifications and Parameters (electromagnetic compatibility and radio Radiation; EN61000-3-2 Harmonics spectrum matters):EMC (electro- EN61000-3-3 +A1: 2001 Flicker (Voltage fluctuation) magnetic compatibility) standards for EN55024 EMS; EN61000-4-2 +A2: 2001 ESD radio equipment and service-Part 17: (Electrostatic discharge);...
  • Page 7 DA05+ WM6 User Manual roda ————————————————————————————— Table of contents GETTING STARTED Unpacking ..................... 10 - CHAPTER 1 - ....9 Quick Check ....................10 Controls, Indicators, and Ports..............11 Operating Environment and Ruggedness............. 15 COMPONENTS AND FUNCTIONS - CHAPTER 2 - ....16 AC adapter ....................
  • Page 8 DA05+ WM6 User Manual roda ————————————————————————————— SPECIFICATIONS CPU....................... 42 - CHAPTER 4 -....41 Memory ......................42 Display......................42 Touch Screen ....................42 I/O ports......................42 System Unit Dimensions and Weight............42 AC Adapter....................42 Battery ......................42 Materials and Recycling ................43 MAINTENANCE / SERVICE Cleaning ......................
  • Page 9 DA05+ WM6 User Manual roda ————————————————————————————— GETTING STARTED Page 9 of 49 —————————————————————————————...
  • Page 10 DA05+ WM6 User Manual roda ————————————————————————————— Unpacking The following components come with your handheld computer. If anything is missing or damaged, please notify the supplier immediately. Handheld computer unit AC adapter AC power cord Vehicle adapter (12-32V) Battery Data sync cable (USB)
  • Page 11 DA05+ WM6 User Manual roda ————————————————————————————— Controls, Indicators, and Ports Front: WLAN BT ANT. GSM/GPRS/UMTS/HSDPA WLAN/BT Battery Charge Button 1 Power Button Button 5 Button 2 Button 3 Button 4 Navigation Button 1. Button 1 (Wireless or Flight button) Turn ON/OFF the wireless device (Option: WLAN, BT, Phone, GPS) 2.
  • Page 12 DA05+ WM6 User Manual roda Rear: (Drawing shows optional GPS and UMTS) ————————————————————————————— 1. Serial Port DB9 Connector 2. Stylus 3. Reset Button 4. Battery Knob 5. Battery 6. Microphone 7. Speaker (under hand strap) Page 12 of 49 —————————————————————————————...
  • Page 13 DA05+ WM6 User Manual roda Left: (Drawing shows optional GPS) ————————————————————————————— 1. Antenna of Wireless Device 2. USB client port (data sync with the computer) 3. USB Host Port 4. Kensington Lock Slot Right: (Drawing shows option GPS and UMTS) 1.
  • Page 14 DA05+ WM6 User Manual roda ————————————————————————————— Top: Serial Port or GPS Antenna Bottom: 1. PCMCIA Slot (type II Slot ) CF (Compact Flash card) will be available by PCMCIA-to-CF adapter. 2. DC Jack 3. Cradle Docking Connector (connection to cradle) Page 14 of 49 —————————————————————————————...
  • Page 15 DA05+ WM6 User Manual roda ————————————————————————————— Operating Environment and Ruggedness If it is necessary to work in a hostile environment, please make sure all ports are well protected from dust, moisture, or water. Proper isolation from extreme hazardous exposure is recommended.
  • Page 16 DA05+ WM6 User Manual roda ————————————————————————————— COMPONENTS FUNCTIONS Page 16 of 49 —————————————————————————————...
  • Page 17 DA05+ WM6 User Manual roda ————————————————————————————— COMPONENTS AND FUNCTIONS AC adapter When using the AC adapter: Use a properly grounded AC outlet. Use one AC outlet exclusively for the computer. Having other appliances on the same line may cause interference.
  • Page 18 DA05+ WM6 User Manual roda ————————————————————————————— Swap Battery Warning: Battery swap should be done within 5 minutes to avoid data loss. To swap the battery: Turn power OFF.  Turn the battery knob counterclockwise to loose the battery.  Remove battery from compartment.
  • Page 19 DA05+ WM6 User Manual roda ————————————————————————————— Cradle (Option) Cradle is the device for docking, port extension, and battery charging. AC adapter may be attached directly to cradle and charged the computer battery as well as the spare battery. The battery slot on the back side of cradle for mounting the spare battery.
  • Page 20 DA05+ WM6 User Manual roda ————————————————————————————— Mount the cradle: 1. Computer may dock either power is ON or OFF (recommend OFF). 2. Align the computer with cradle docking connector. 3. Firmly push the computer down to engage the docking connector.
  • Page 21 DA05+ WM6 User Manual roda ————————————————————————————— PCMCIA Slot The PCMCIA slot accepts one type-II card. Insert the card firmly into the slot and fix the rubber cover for water/dust protection. To remove the card, push the eject button to pop out the card. The eject button can hide into the compartment by pushing it inward gently.
  • Page 22 DA05+ WM6 User Manual roda ————————————————————————————— BASIC OPERATION Page 22 of 49 —————————————————————————————...
  • Page 23 DA05+ WM6 User Manual roda ————————————————————————————— BASIC OPERATION Active Sync over USB client Tap Start  Settings  Connection  USB to PC  enable "Advance network functionality" This option is needed for correctly functionality of ActiveSync over USB-Client. If there are connection problems disable this option.
  • Page 24 DA05+ WM6 User Manual roda ————————————————————————————— Owner Information Tap Start  Settings  Personal  Owner Information Follow the descriptions. On the identification tab, enter your personal information. Tap Options select “Show information when device is turn on” your information will be displayed once power ON.
  • Page 25 DA05+ WM6 User Manual roda ————————————————————————————— Reset the system (Refer “Controls, Indicators, and Ports” for button location) Soft Reset Warning: Data not saved will be lost, and some settings will be lost (ex. portrait/landscape) Try a soft reset when: The device does not respond when tapping the display.
  • Page 26 DA05+ WM6 User Manual roda ————————————————————————————— Clean Boot (Emergency Clear) Warning: All data, either in RAM or saved in flash memory will be lost, all registry and user programs will be lost, and all settings will be reset back to factory default. Only OS and factory bundled programs are intact.
  • Page 27 DA05+ WM6 User Manual roda ————————————————————————————— Wireless LAN (Option) Connect to Internet: Turn on the Wireless Signals. Tap Start  Settings  Connections. (Or directly press button to enter Figure 1-2) Tap Wireless Manager and select ON for checkbox <WiFi>...
  • Page 28 DA05+ WM6 User Manual roda ————————————————————————————— Access to the Intranet: Please refer to step 1.1 ~ step 1.4. Select Work option, if the intranet access is via Proxy Server, it needs to be set later. (Figure 2-1). Tap Start  Settings  Connections and tap Connections icon.
  • Page 29 DA05+ WM6 User Manual roda ————————————————————————————— GSM/GPRS/UMTS/HSDPA (Option) SIM card slot is below the lable. Remove and replace with attached label before use. Make sure the SIM card is mounted correctly then install the battery. SIM slot is under battery (Figure 3-1). Stick the label to seal the SIM slot (usually supplier had done it already).
  • Page 30 DA05+ WM6 User Manual roda ————————————————————————————— GPRS/HSDPA Tap Wireless Manager and select ON for checkbox <Phone> (Figure 1-1 & 1-2). Phone function is enabled. Tap Start  Settings  Connections and select “Add a new modem connection” under “My ISP” item. (Figure 4-3)
  • Page 31 DA05+ WM6 User Manual roda ————————————————————————————— Page 31 of 49 —————————————————————————————...
  • Page 32 DA05+ WM6 User Manual roda ————————————————————————————— Bluetooth (Option) 1. Beam File function: FTP Profile supports devices to transfer file. Turn on Bluetooth via Wireless Manager. Tap Start  Settings  Connections Bluetooth. (Figure 1-1) Tap Start  Settings  Connections Beam and make sure that the “Receive all incoming beams”...
  • Page 33 DA05+ WM6 User Manual roda ————————————————————————————— 2. OBEX Profile: OBEX Profile supports devices to exchange data. Turn on Bluetooth via Wireless Manager. Tap Start  Settings  Connections  Bluetooth. (Figure 2-1) Tap Mode and make sure that both “Turn on Bluetooth” and “Make this device visible to other devices”...
  • Page 34 DA05+ WM6 User Manual roda ————————————————————————————— Page 34 of 49 —————————————————————————————...
  • Page 35 DA05+ WM6 User Manual roda ————————————————————————————— 3. FTP Profile: FTP Profile supports transfer file between Bluetooth devices. Turn on Bluetooth via Wireless Manager. Please refer to step 2.1 ~ step 2.6. Tap highlight icon “FTP Service” from PC’s IVT Soleil program then transfer Naming card to device.
  • Page 36 DA05+ WM6 User Manual roda ————————————————————————————— 4. ActiveSync Profile: ActiveSync Profile supports the use of ActiveSync over a Bluetooth connection. Turn on Bluetooth via Wireless Manager. Make sure the USB Activesync cable not connected to PC Tap Start  Settings  Connections. (Figure 2-1) Tap Bluetooth ...
  • Page 37 DA05+ WM6 User Manual roda ————————————————————————————— 6. Hands-Free/HandSet Profile: Handset profile supports interoperability between a headset and a mobile device, such as a cellular phone. Hands-Free Profile supports conjunction with a hands-free device over Bluetooth. Turn on Bluetooth via Wireless Manager.
  • Page 38 DA05+ WM6 User Manual roda ————————————————————————————— 7. SPP Profile: Turn on Bluetooth via Wireless Manager. Prepare a Bluetooth device that support SPP profile (Like Bluetooth GPS), and set the device into pairing mode. Tap Start  Settings  Connections. (Figure 2-1) Tap Bluetooth ...
  • Page 39 DA05+ WM6 User Manual roda ————————————————————————————— 8. HID Profile: Turn on Bluetooth via Wireless Manager. Prepare a Bluetooth device that support HID profile (Like Bluetooth mouse or keyboard), and set the device into pairing mode. Tap Start  Settings  Connections Tap Bluetooth ...
  • Page 40 DA05+ WM6 User Manual roda ————————————————————————————— GPS (Option) Press Button 1 to launch Wireless Manager. Click Settings on the right side of the GPS On/Off switch, the Setting GPS Antenna dialog will pop up; select the antenna type for your current setup: Internal: Use internal GPS antenna, default setting.
  • Page 41 DA05+ WM6 User Manual roda ————————————————————————————— SPECIFICATIONS Page 41 of 49 —————————————————————————————...
  • Page 42 DA05+ WM6 User Manual roda ————————————————————————————— SPECIFICATIONS Marvell PXA270 CPU speed 624MHz 128MB Memory Type: 4” Active TFT Transflective Color LCD Display Resolution: 480 x 640 pixels Color: Backlight: Type: Resistive Touch Screen Interface: Serial USB 2.0 port I/O ports...
  • Page 43 DA05+ WM6 User Manual roda ————————————————————————————— Materials and Recycling Materials of the computer are as follows: Cabinet: Aluminum alloy ADC-12 or A380 Magnesium alloy AZ91D UL grade PC+ABS GE C6200 or TN-3813BW Bracket: Aluminum 5052, steel with Nickel plating, or stainless Steel S304...
  • Page 44 DA05+ WM6 User Manual roda ————————————————————————————— MAINTENANCE / SERVICE Page 44 of 49 —————————————————————————————...
  • Page 45 Fax: +49 5744-944 475 E-Mai: support@roda-computer.com Note: The roda Service Center needs a detailed description of the problem and the serial number of the device. If it is necessary to send in your computer for repairs, you can download a service waybill (Service Supply Note) on the roda homepage (www.roda-...
  • Page 46 Place and date of purchase or the original invoice number Date of failure A DETAILED description of the problems you have encountered A list of the hardware/ software configuration, if applicable Check our website (www.roda-computer-com) for downloads: Updates Drivers Manuals...
  • Page 47 DA05+ WM6 User Manual roda ————————————————————————————— Environmental Ratings Page 47 of 49 —————————————————————————————...
  • Page 48 DA05+ WM6 User Manual roda ————————————————————————————— Environmental Ratings MIL-STD-810 Standards Storage Operating Remarks Low pressure (Altitude) DA05+M w/ CR05+ 21,287m 12,180m MIL-STD-810F 500.4 procedure I, High temperature DA05+M w/ CR05+ MIL-STD-810F 501.4 procedure I, + 70C + 50C At 50C...
  • Page 49 DA05+ WM6 User Manual roda ————————————————————————————— IEC IP Standards Storage Operating Remarks Powder type: Talcum DA05+I IEC 60529 IP5x * Dust amount: 2kg/1 m³ CR05+ Dust Test Test duration: 8 hours CHR05 Tube radius: 400mm DA05+I IEC 60529 IPx4 *...
