Illuminators LL RG4, LL RG6, LL RG4 CG, LL RG4 CG
1.1
General health and safety instructions
2.1
Intended use
3.1
Scope of supply
3.2
System description
4.1
Mounting
5.1
Wiring
6.1
Marking
7.1
Maintenance
8.1
Disposal
9.1
Warranty
24010 Ponteranica (Bergamo) ITALY - Via Serena, 10 - Tel. +39 035 4530211 - Fax +39 035 570546 -
******************************************************************************************************************************************************************
GEN. 2020
OFFICINE OROBICHE
INSTRUCTION MANUAL
www.officineorobiche.i t- e-mail:info@officineorobiche.it
Information subject to change without prior notice
/
1
10
IST/192-I
Advertisement
Table of Contents
Related Manuals for OFFICINE OROBICHE LL RG4
Summary of Contents for OFFICINE OROBICHE LL RG4
- Page 1 OFFICINE OROBICHE INSTRUCTION MANUAL Illuminators LL RG4, LL RG6, LL RG4 CG, LL RG4 CG General health and safety instructions Intended use Scope of supply System description Mounting Wiring Marking Maintenance Disposal Warranty 24010 Ponteranica (Bergamo) ITALY - Via Serena, 10 - Tel. +39 035 4530211 - Fax +39 035 570546 - www.officineorobiche.i t- e-mail:info@officineorobiche.it...
-
Page 2: General Health And Safety Instructions
OFFICINE OROBICHE 2/10 1.1 General health and safety instructions Avoidance of danger for persons and property • Only use unit for intended purpose. • No additional mountings and modifications on the unit without our approval. • Adhere to the standards for prevention of accidents and to the plant specific safety regulations. -
Page 3: Scope Of Supply
OFFICINE OROBICHE 3/10 As a result the water compartment always appears green and the steam compartment red. 3.1 Scope of supply The LL RGx illuminator are delivered in 3 parts. (see fig. 1) Part 1 consists of: • illuminators Part 2 consists of: •... - Page 4 OFFICINE OROBICHE 4/10 Part 1 Illuminator with round connector Illuminator with cable gland (standard version) (special version) Without Sunshade With Sunshade With removable Sunshade 24010 Ponteranica (Bergamo) ITALY - Via Serena, 10 - Tel. +39 035 4530211 - Fax +39 035 570546 www.officineorobiche.it - e-mail:info@officineorobiche.it...
-
Page 5: System Description
OFFICINE OROBICHE 5/10 Part 2 Steel enclosure Part 3 Power supply unit Fig. 3.2 Without Sunshade Fig. 3.3 With Sunshade 3.2 System description ILLUMINATOR The illuminator is modular and has two different sizes, six pixels (three green and three red) and four pixels (two green and two red). - Page 6 Six pixels with round connector: LL RG6 Four pixels with cable gland: LL RG4 CG Six pixels with cable gland: LL RG6 CG The complete illuminator will be fixed to the steel cabinet with four screws, position of one respect to another is fixed in order to maintain the distance from the pixels (see fig.
- Page 7 OFFICINE OROBICHE 7/10 When the illuminators are supplied with circular connectors wiring is ready for plug and play, enclosure has the right quantity of cables and connectors to be connected to the illuminators, cable length has to be defined in the order description.
- Page 8 OFFICINE OROBICHE 8/10 5) Fix the last steel plate to close the enclosure always using M5 screws, connect all the cables using the round connector locking the male stopper and apply the cable protection using some of the M5 screws 24010 Ponteranica (Bergamo) ITALY - Via Serena, 10 - Tel.
-
Page 9: Identification Plate / Marking
OFFICINE OROBICHE 9/10 5.1 Wiring To connect the main power supply provide a 3x2,5 mm2 to be connected to the dedicated terminals inside the power unit. Earth terminal has to be connected to the ground properly and power supply has to be protected as per country regulation. -
Page 10: Warranty
All the illuminator device are guaranteed to be free from manufacturing faults over a period of 12 months from the date of shipment. In the event of failures, implying return of goods within the limit specified above, OFFICINE OROBICHE will replace (shipment fees not included) all damaged parts free, provided that the failure does not ensue from incorrect use.
