V-4408D EIGHT-CHANNEL
NETWORK VIDEO RECORDER (NVR)
Installation Guide
Figure 1: V-4408D Network Video
Recorder (NVR)
DESCRIPTION
The SecureCom™ Video V-4408D
Eight-Channel NVR connected to
residential or commercial systems
gives users a more powerful
security tool to monitor cameras
connected to their systems.
The V-4408D provides Power over
Ethernet (PoE) capability, allowing
you to supply power to a network
camera using the same cable that
transmits the data.
The V-4408D provides 2 TB of
storage for around the clock, local
recording. The V-4408D supports all
ONVIF 2.4-compatible cameras and
is viewable on the Virtual Keypad™
App or VirtualKeypad.com and can
be monitored from any monitor with
and HDMI cable or with Apple TV
(Virtual Keypad™ App required).
•
4000 or 5000 Series
SecureCom Video Cameras
•
ONVIF-Compliant Cameras
•
Hikvision Cameras
What is Included?
•
SecureCom Video V-4408D
Eight-Channel NVR
•
Power cable
•
Three-button USB mouse
•
6 ft Network cable
•
Hard drive cable
•
Hardware pack
1
INSTALL THE V-4408D
1.
Attach the included power cable to the back of the NVR.
See Figure 2.
2.
Attach the other end of the power cable into a wall outlet.
3.
Power on the NVR with the switch on the back.
2
CONNECT THE DEVICES DIRECTLY
Connect cameras and any peripheral devices to the ports in the
back of the NVR. See Figure 2 for port locations.
LAN
Connect the NVR directly to the customer's network using the
LAN port.
USB
Connect USB devices like a mouse, keyboard, flash drive, or an
external hard drive to the NVR using the two built-in USB ports.
HDMI
Connect one end of the HDMI cable to the NVR and the other
end to a TV or monitor to monitor video.
Hikvision and 4000 Series
Can only be automatically learned in if they are plugged into the
camera ports on the back of the NVR.
5000 Series
Cannot be plugged in to the ports on the back of the NVR. Also
requires that a DHCP reservation is set up on the router. For more
information, refer to the documentation for your router model.
8 Camera Ports
1
2
3
5
6
7
Figure 2: V-4408D Ports
LAN
HDMI
4
AUDIO IN
LAN
8
AUDIO OUT
VGA
HDMI
USB
Power
On/Off
Switch
Power
Switch
