FITTING INSTRUCTIONS - NOTICE DE POSE - MONTAGE HANDLEIDING - MONTAGEANLEITUNG
Warranty. This product is covered by a 10 year manufacturer's warranty. Please see the P C Henderson website for terms and conditions.
WATCH THE INSTALLATION VIDEO
Visit: www.pchenderson.com/soltaire-installation
Or scan the QR code using your phone
NOTE: If installing with Planet Drop Seal, please use both fitting instructions in conjunction as door overlap and routing detail differs slightly.
51/120/SS Hanger
Soffit Fix
41
31
19 - 32
Door
Thickness
24 - 48
3-15
17
21
Channel 94/94X
For MDF doors 19-23mm you must use hanger 52/120/SS and for doors 24-48 there is an option of surface mounted or routed (51/120/SS or 57/120/SS)
ISTRUZIONI DI MONTAGGIO - INSTUCCIONES DE MONTAJE
Face Fix
Hanger bracket
1/SS
120 Track
21
20
SOLTAIRE 120
Fitting Instructions (Stainless Steel)
12
66
12 - 24
Channel
94/94X
20
20
3-15
3-15
57/120/SS Hanger
Face Fix
Soffit Fix
Hanger bracket
1/SS
41
Door
Thickness
24 - 48
21
20
12
66
120 Track
3-15
17
Channel 94/94X
21
Advertisement
Table of Contents
Related Manuals for Henderson SOLTAIRE 120
Summary of Contents for Henderson SOLTAIRE 120
- Page 1 FITTING INSTRUCTIONS - NOTICE DE POSE - MONTAGE HANDLEIDING - MONTAGEANLEITUNG ISTRUZIONI DI MONTAGGIO - INSTUCCIONES DE MONTAJE Warranty. This product is covered by a 10 year manufacturer’s warranty. Please see the P C Henderson website for terms and conditions. WATCH THE INSTALLATION VIDEO Visit: www.pchenderson.com/soltaire-installation...
