Henderson 80/2 Fitting Instructions Manual

FITTING INSRUCTIONS – NOTICE DE POSE – MONTAGE HANDLEIDING – MONTAGEANLEITUNG
Maximum Door Width = 1200mm
Door Thickness Range = 32 > 47mm
Contents of Kit
Short Arm
80/2 x 1
80/3 x 2
Long Arm
80/2 x 1
80/3 x 2
Datum Block
80/2 x 1
80/3 x 1
Universal clip stop
80/2 x 2
80/3 x 2
80/2 & 80/3 Telescopic system
ISTRUZIONI DI MONTAGGIO – INSTUCCIONES DE MONTAJE
System Specification
Belt Joint bracket
x 1
x 2
Fixed Floor guide
x 1
x 1
Spanner
x 1
x 1
Toothed belt
(Metres)
x 3 m
x 5 m
Minimum Door Width = 500mm
Maximum Weight per Leaf (80/2 & 80/3) = 80kg
Belt retain block
x 1
x 1
Adjustable floor guide bracket Adjustable floor guide foot
x 1
x 2
Husky Hanger & Apron plate
x 4
x 6
Belt clamp
x 3
x 6
x 1
x 2
Second door bracket
x 0
x 1
