Alzatex ALZML08A Quick Start Manual

ALZML08A

Product

Presentation Timer w/ Large LED Display

Description:

This presentation TimeKeeper™ system includes
a KP215ASM Count Up/Down Timer with three
programmable presets, and a DSP504B Large Four-digit
LED wall Display visible (up to 100ft) to the speaker and
the audience.
Item: ALZML08A
UPC: 788581652312
EAN: 0788581652312
Stock Status: Usually in stock.
Dimensions: 21.5" x 8" x 2.5"
Weight: 8.1 lbs.
MSRP: $649.00

Specifications

•
(1) Two Serial data RJ11 connectors for accessories.
•
(1) One RS422 output with RJ45 connector for
accessories.
•
(1) Ground closure 600mA output for optional beeper.
(not included).
•
(1) Timer Construction: Metal enclosure, black powder
coated finish.
•
(1) Display Construction: Metal enclosure, black powder
coated finish.
•
(1) Power requirements: 10-18 VAC or 12-24 VDC
power.
•
(1) Current consumption: 500ma.
•
(1) KP215ASM Dimensions: 2.85" x 1.8" x 1.32".
•
(1) DSP504B Dimensions: 21.5" x 8" x 2.5".

Mounting methods

•
(1) Standard mounting is 2 key hole slots spaced 16inch
apart for wall mounting.
•
(1) There are screws at either end of the displays where
D-Rings can be added. D-Rings are NOT included and
may be ordered separately.
•
(1) 1/4-20 nuts on the bottom of the unit for attaching a
tripod adapter or feet. The feet and tripod adapter is NOT
included and may be ordered separately.
•
(1) The display has holes in the top for adding a
handle. The handle is NOT included and may be ordered
separately.

Features

•
(1) Count up elapsed timer settable to Hour:Min or
Min:Sec.
•
(1) Count down time remaining timer settable to
Hour:Min or Min:Sec.
•
(1) Easy to use. Press Reset. Turn knob to set the
desired time. Press Start.
•
(1) Subsequent timing cycles. Press Reset. The time
previously used will be loaded. Press Start.
•
(1) Green, Yellow and Red warning indicators have
preprogrammed settings to match Toastmasters
requirements, or may be programmed by user.
•
(1) Four-digit LED seven-segment Display with 0.56"
high digits.
•
(1) Beeper provides audible sound when timer reaches
zero.
•
(1) Button to turn beeper on/off.
•
(1) Built in Time of day clock displays 12 or 24 hour
mode.
•
(1) Connect two or more TimeKeepers™ together.
One becomes the timer, and the others become remote
displays.
•
(1) Made of ruggedized aluminum construction.

Item Includes

•
(1) KP215ASM Count up/down timer
•
(1) DSP504B Large LED display
•
(1) WT12VAC1200MA-RA 12V AC, 1200 MA
Transformer.
•
(1) M8BK025F 25ft Cable, CAT-5.
•
(1) RC Reference card
