Thermoplastic Enclosures - Scame ISOLATORS 590.SEM3203 Quick Start Manual

ISOLATORS Series

THERMOPLASTIC ENCLOSURES

20÷40A
2P-3P-3P+N
100
Max Ø6 mm
ATTENTION
When mounting or removing additional elements
the switch has to be in OFF position for
avoiding damages to mechanism.
When removing main switch following istruction
for avoiding damages.
MP39751
50
15
122
No. 2 M5 FASTENING DEPTH=8,5
-2-
L
L/2
