- Page 1 PMV Remote D3 Potentiometer Calibration How to calibrate potentiometer in F5NU-MECPOT with Remote D3 positioner...
- Page 2 Removal of D3 Cover...
- Page 3 Mount the remote feedback unit onto the actuator...
- Page 4 PMV D3 only. Max recommended distance between PMV D3 and the remote feedback unit: 5 m (16.4 ft). NOTE: If D3 will be further than 5 m from the valve then you might need to increase the air tubing to 3/8” I.D.
- Page 6 Calibrating the Potentiometer 1. With power applied to the D3, use the key pad and navigate to CALIBRATE > EXPERT CAL > POT. The D3 display should now read like 1. 2. Press the Down arrow key to stroke the valve to the correct position. Press the OK button once valve is at 0% position.
- Page 7 Insert F5-22 tool into slot in bottom white gear wheel Follow on-screen instructions to determine which direction to rotate gear wheel. Hit OK button once display says POT OK. Contact pmvsales@flowserve.com for additional information...
