OCENAV ATM105A1N/2/3-MULTIPLEXER GATEWAYS and
ATM200-DATALOGGER (V2.xx)
Contents
1. General operation: ............................................................................. 2
1.1- Protocols and Input / Output channels: ...................................... 3
1.2- Data input filtering: ............................................................................. 4
1.3- Calculation of the "Performance" data: ....................................... 6
1.4- Output data filtering: .......................................................................... 7
1.5- Data transmission:............................................................................... 8
1.6- Base station for the remote control: ............................................. 8
1.7- Alarms center: ....................................................................................... 9
1.8- Datalogger: (ATM200) .................................................................... 10
2. Before you install the device: ...................................................... 12
3. Installation: ....................................................................................... 15
4. Wifi, NMEA183 and NMEA2000 Configuration: .................... 17
5. Software updates:............................................................................ 19
6. Technical data: ................................................................................. 19
OCENAV ATM105A1N/2/3, ATM200
1
Advertisement
Table of Contents
Related Manuals for OCENAV ATM105A1N
Summary of Contents for OCENAV ATM105A1N
-
Page 1: Table Of Contents
OCENAV ATM105A1N/2/3, ATM200 OCENAV ATM105A1N/2/3–MULTIPLEXER GATEWAYS and ATM200-DATALOGGER (V2.xx) Contents 1. General operation: ................2 1.1- Protocols and Input / Output channels: ........3 1.2- Data input filtering: ................4 1.3- Calculation of the “Performance” data: ........6 1.4- Output data filtering: ................7 1.5- Data transmission:................ -
Page 2: General Operation
OCENAV ATM105A1N/2/3, ATM200 1. General operation: The ATM105A1N / 2/3 and ATM200 are triple protocol gateways and operate in real time following the following process: 1) Reception of the data sent by the navigation instruments in any protocol (NMEA0183, NMEA2000 and Seatalk ™) in the... -
Page 3: Protocols And Input / Output Channels
There can only be one transmitting device on each RS232 / RS422 channel, but up to 3-4 receivers can be connected: The Ocenav gateway units have up to 3 optocoupled RS422 input channels (receivers) with speeds from 4800 to 115200 baud, up to 2 output RS422 channels... -
Page 4: Data Input Filtering
Area Network" (CAN Bus), consisting of 5 wires: NET+, NET-, +12v, Ground and Shield. It is a bidirectional bus. The communication speed is 250k bits per second. With the exception of ATM105A2, all OCENAV centrals have NMEA2000. More information at: https://en.wikipedia.org/wiki/NMEA_2000... - Page 5 OCENAV ATM105A1N/2/3, ATM200 main GPS, secondary is enabled automatically., and data flow is updated. The order of priority is established based on the HDOP sent by each GPS / GNSS receiver connected to the gateway, and the lowest value is taken.
-
Page 6: Calculation Of The "Performance" Data
OCENAV ATM105A1N/2/3, ATM200 The same is true for log speed, heading error (XTE), and rudder angle data. The ATM105A generates magnetic declination if it is not receiving it from a GPS device. The user can also force this calculation by selecting “Generate Magnetic variation (declination) in the setup. -
Page 7: Output Data Filtering
Output data Filtering: Unlike other existing gateways on the market, the ATM105A1N / 2/3 and ATM200 establish a rotating output sequence that is optimal to avoid both overflow and to ensure that all data is sent in a short space of time. time over slow NMEA0183 channels. -
Page 8: Data Transmission
/ or to add more equipment to the system. 1.5.2- Seatalk, NMEA2000 or NMEA0183 links: Two OCENAV gateways can be linked to each other through any of their BUSES. Seatalk and NMEA2000 can be used, although channel 2 of NMEA0183 configured to 115200 can also be used to increase speed. -
Page 9: Alarms Center
OCENAV ATM105A1N/2/3, ATM200 1.7- Alarms center: There is an optional alarm module configurable by the user through a WEB form sent by the gateway. The available alarms are: - Maximum apparent wind. - Minimum depth. - Low quality GPS data. GPS failure. -
Page 10: Datalogger: (Atm200)
OCENAV ATM105A1N/2/3, ATM200 1.8- Datalogger: (ATM200) The ATM200 has a socket for microSD cards. The user can select the data to be recorded, its frequency and duration of each data file, by editing the CONF200.txt file present on the same microSD card:... - Page 11 OCENAV ATM105A1N/2/3, ATM200 capture within a radius of 0.5 miles and that exceeds the speed of 0.5 knots. Example. The following block of data is part of a file created to track approaching ships while in port. Only AIS and...
-
Page 12: Before You Install The Device
ATM105A gateway must be considered, taking into account the following: - All Ocenav Gateways have a Seatalk Bus and only require a connection at any point in that network (Red / Yellow / Black). - Page 13 OCENAV ATM105A1N/2/3, ATM200 - The AIS receivers can connect to the NMEA2000 Bus or in the channels IN3 (ATM105A2 / A3) - autobaud, or NMEA0183 IN2 (ATM105A1) changing the speed of NMEA0183 to 38400 (Config. WiFi).-AIS information will be sent via WiFi and...
- Page 14 OCENAV ATM105A1N/2/3, ATM200 - It is possible to eliminate the existing NMEA0183 cable between the GPS and an STxxxx or SmartPilot S2 / S3 pilot, since the ATM105 translates the sentences from NMEA to Seatalk and vice versa. This cable can be reconnected to the...
-
Page 15: Installation
OCENAV ATM105A1N/2/3, ATM200 3. Installation: In order to ensure correct operation and avoid possible breakdowns, it is recommended that the installation be carried out by a specialized installer, otherwise, any responsibility is declined. - This device must be screwed to a vertical base, with the... - Page 16 OCENAV ATM105A1N/2/3, ATM200 The connections between this device and the instruments with differential inputs / outputs (RS422) are made directly: the instrument outputs (+ or A), (- or B) are connected to the ATM105A inputs (+ or A with + , and - or B with -). In the same...
-
Page 17: Wifi, Nmea183 And Nmea2000 Configuration
4) Use an internet browser to access the home page www.ocenav.com. Usually appears as a popup window. If you have problems with access, clear your browser history. 5) On the home page, press “Change configuration” to access the... - Page 18 OCENAV ATM105A1N/2/3, ATM200 The default parameters* are: Device in Access Point mode (AP). SSID (Access Point Name): OCENAVxxxxx Access Point Password: atm105xxx Connetion mode: UDP broadcast / multicast UDP address: 45.0.20.1 UDP Port (device): 1433 UDP Port (host): 2433 Notes (*): All these values are modifiable by the user.At this point,...
-
Page 19: Software Updates
It is recommended that this operation be carried out by an authorized installer, or failing that, that the user register with OCENAV by sending an email providing the serial number and installed version. OCENAV will not assume any responsibility otherwise. - Page 20 OCENAV ATM105A1N/2/3, ATM200 Maximum current through NMEA0183 inputs: 5mA Maximum current supplied by NMEA0183 outputs: 15mA Maximum current of ANCHOR outputs: 1A. WIFI: 802.11 b / g / n protocol, power: 10, 15 and 20 dB. Complete transceiver (transmission and reception) 100% compatible with Seatalk, NMEA0183 and NMEA2000.
