HT904TA-DHP_BGBRLL_ENG_0728
Model : HT904TA (HT904TA-DHP, SH94TA-F/S/C/W)
HT904SA (HT904SA-DHP, SH94SA-S/C/W)
HT904PA (HT904PA-DHP, SH94PA-F/S/C/W)
FOR THE WARRANTY TERMS & CONDITIONS,
PLEASE REFER TO BACK COVER OF THIS MANUAL.
Full HD up-scaling (1080p)
(Go to page 6)
USB Direct Recording
(Go to page 17)
iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
As an E
S
®
NERGY
TAR
LG has determined that this
product or product models meet
the E
S
®
guidelines for
NERGY
TAR
energy efficiency.
E
NERGY
S
TAR
®
is a U.S. registered mark.
P/NO : MFL60020728
3/12/09
11:42 AM
Page 1
HDMI In
(Go to page 7)
Made for iPod
(Go to page 18)
Partner,
Home theater Speaker ez Set-up
(Go to page 15)
Portable In
(Go to page 19)

Advertisement

Table of Contents
loading

Related Manuals for LG HT904TA

Summary of Contents for LG HT904TA

  • Page 1 HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Model : HT904TA (HT904TA-DHP, SH94TA-F/S/C/W) HT904SA (HT904SA-DHP, SH94SA-S/C/W) HT904PA (HT904PA-DHP, SH94PA-F/S/C/W) FOR THE WARRANTY TERMS & CONDITIONS, PLEASE REFER TO BACK COVER OF THIS MANUAL. Full HD up-scaling (1080p) (Go to page 6) USB Direct Recording (Go to page 17) iPod is a trademark of Apple Inc., registered in the U.S.

  • Page 2: Safety Precaution

    This product is manufactured to comply with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC. European representative : LG Electronics Service Europe B.V. Veluwezoom 15, 1327 AE Almere, The Netherlands (Tel : +31-036-547-8940)

  • Page 3: Table Of Contents

    Some functions of this unit are controlled by TV’s remote control when this unit and LG TV with SIMPLINK are connected through HDMI connection. • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc.

  • Page 4: Setting Up

    Setting up The speakers are detached from the speaker stands. Assembling the Speakers (HT904TA, HT904PA) 1 Attach the speakers to the speaker stands by rotating the screw. 2 If you want to arrange the speaker cable, draw the speaker cable through the hole on the speaker.

  • Page 5: Hooking Up The Unit

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Check the jacks of your TV, and choose the A, B or C connection. Picture quality improves in order from A to C.
  • Page 6 HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Hooking up the unit Resolution Setting You can change the resolution for component video and HDMI output. Press RESOLUTION repeatedly to select the desired resolution - 480i (or 576i), 480p (or 576p), 720p, 1080i, 1080p The resolution may not be selected depending on the connection or TV.

  • Page 7: Main Unit

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Hooking up the unit HDMI In connection Connect the HDMI INPUT jack on the unit to the HDMI output jack on your Set-Top box (or Digital Device etc.) using an HDMI cable. Set the external source to HDMI IN by pressing FUNCTION.

  • Page 8: Remote Control

    0-9 numerical buttons : Selects numbered options in a menu. ) : Selects programme of Radio. TV Control buttons : Controls the TV. (LG TV only) Controlling the TV. You can control the sound level, input source, and power switching of LG TVs as well. Hold POWER (TV) and press PR/CH (+/–) button repeatedly until the TV...

  • Page 9: Osd Initial Language Settings - Optional

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM OSD Initial language settings - Optional During the first use of this unit, the initial language setup menu appears on your TV screen. You must complete initial language selection before using the unit. English will be selected as the initial language.

  • Page 10: 5.1 Speaker Setup

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Adjusting the display settings TV Aspect – Select which screen aspect to use based on the shape of your TV screen. [4:3] : Select when a standard 4:3 TV is connected. [16:9] : Select when a 16:9 wide TV is connected.

  • Page 11: Enjoying A Preprogrammed Sound Field

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Adjusting the lock settings To access the lock options, you must enter the 4-digit password. If you have not yet entered a password you are prompted to do so. Enter a 4-digit password then press ENTER. Enter it again then press ENTER to verify. If you make a mistake while entering number, press CLEAR then correct it.

  • Page 12: Displaying Disc Information

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Displaying Disc Information 1 Press DISPLAY : 2 Select an item : 3 Adjust the Display menu settings : 4 To return the exit : Displaying Disc Information - more you can do U U u u...
  • Page 13 HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Fast forward or fast reverse Press SCAN (m or M) to play fast forward or fast reverse during playback. You can change the playback speed by pressing SCAN (m or M) repeatedly. Press PLAY (B) to continue play at normal speed.

  • Page 14: Viewing Photo Files

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Creating your own program You can play the contents of a disc in the order you want by arranging the order of the musics on the disc. To add a music(s) on the program list, press PROG/MEMO to enter the program edit mode ( mark appears on the menu).

  • Page 15: Listening To The Radio

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Listening to the radio Be sure that FM aerials are connected. 1 Turn the power on : 2 Select FM : 3 Select a radio station : 4 To ‘save’ a radio station : A preset number will show in the display.

  • Page 16: Using An Usb Device

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Using an USB device You can enjoy media files saved on an USB device by connecting the USB device to the USB port of the unit. If you want to operate other function, see the CD playback section.

  • Page 17: Usb Direct Recording

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Recording to USB 1 Connect the USB device to the unit 2 Select a mode in which you want to record (ex. CD/ TUNER...) Play back a sound source first If you want to record desired music file in Disc to USB.

  • Page 18: Playing The Ipod

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Playing the iPod For detial refer to iPod guide. iPod mode: You can operate your iPod by using the supplied remote control and directly control on your iPod. OSD iPod mode: You can operate your iPod by controlling OSD menu on the TV screen with supplied remote control.

  • Page 19: Listening To Music From Your Portable Player Or External Device

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Listening to music from your portable player or external device The unit can be used to play the music from many types of portable player or external device. Connect the portable player to the PORT.IN(PORTABLE IN) connector of the unit.

  • Page 20: Language Codes

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Afar 6565 Croatian 7282 Afrikaans 6570 Czech 6783 Albanian 8381 Danish...

  • Page 21: Troubleshooting

    HT904TA-DHP_BGBRLL_ENG_0728 3/12/09 11:42 AM Troubleshooting PROBLEM CAUSE No power The power cord is disconnected. No picture The TV is not set to receive the DVD signal. The video cables are not connected securely. There is little or no sound Equipment connected via the audio cable is not set to receive DVD signal output.

  • Page 22: Types Of Playable Discs

    You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players. (Mastered/ Live File System : Disc format system for Windows Vista)

  • Page 23: Specifications

    Rated Input Power 155 W Max. Input Power 310 W Net Dimensions (W x H x D) 350 x 105 x 93 mm Net Weight 1.5 kg Speakers (HT904TA) Front Speaker Type 2 Way 3 Speaker Passive 4 Ω Impedance...
  • Page 24 3/12/09 11:42 AM ● LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee. 1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period of 12 months from the original date of purchase.
