inStruCtiOn MAnuAl
Orion
Camera Small Pole Mount
Suitable for poles with diameter 50 mm to 130 mm
#24431 (parts #5858 & #5860)
Parts list
Wall Mount
• Bracket arm
• Swivel head
• 4x short Hexagonal head screws
• Hexagonal Allen Key
• 4x Philips head screws
• 4x Wall plugs
• 4x washers
Providing Exceptional Consumer Optical Products Since 1975
Customer Support (800) 676-1343
E-mail: support@telescope.com
Starshoot
®
Oriontelescopes.com
Corporate Offices (831) 763-7000
89 Hangar Way, Watsonville, CA 95076
© 2011 Orion Telescopes & Binoculars
AllSky
™
Pole Mount
• 2x Pole mount sides
• 2x Long bolts
• 4x nuts
IN 431 Rev. A 10/11
