- Page 1 Assembly Instructions Adjustable Plyometric Box STYLE #SLBCFA6014 Please keep this instruction manual for future reference Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily) Live Chat at: www.academy.com Email: customerservice@academy.com (Made in China)
-
Page 2: Table Of Contents
Table of Contents Warnings………………………………………………………………..….2 Tools and Parts…………………………………………………………..3 Assembly Instructions…………………………………………………..4 Care and Maintenance……………………………………………...……8 Warranty Information……………………………………….....8 Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit. -
Page 3: Warnings
Warnings • Read this manual before assembling or using this product. • Check product for loose or broken parts before each use. • Discontinue use when any missing, broken, and loose parts are found. • Before beginning any exercise program, consult your physician. •... -
Page 4: Tools And Parts
Parts List DESCRIPTION DIAGRAM Platform Main frame component Support tubes Adjustable leg Hardware Bolts (M8x35mm) Long bolts (M8x90mm) Washer Nut (M8) Quick release pin Tools (included) Wrench... -
Page 5: Assembly Instructions
Assembly Instructions Step 1: Attach main frame component (2) to platform (1) using long bolts (6), washers (7) and nuts (8) as shown in Figure 1. NOTE: Place platform (1) with rough side down on a soft surface to avoid damage to flooring or other objects as shown in Figure 1. - Page 6 Assembly Instructions Step 2: Attach the support tubes (3) to main frame component (2) using bolts (5), washer (7) and nut (8) as shown in Figure 2. Figure 2...
- Page 7 Assembly Instructions Step 3: Attached adjustable leg (4) to main frame component (2) using quick release pin (9) as show in Figure 3. TIP: AFTER FINISHING ALL STEPS ABOVE, GO OVER THE ENTIRE UNIT AND TIGHTEN ALL BOLTS. LONGER ENDS MUST FACE OUTWARD Figure 3...
- Page 8 Assembly Instructions Step 4: Assembly completed. The height of product can be adjusted to 5 different heights. To adjust each adjustable leg (4), remove the quick release pin (9) and slide the keg upward or downward to the desired height and insert the quick release pin (9) through frame and legs.
-
Page 9: Care And Maintenance
Care And Maintenance Avoid dropping the product. Do not use or store in wet or humid conditions. Wipe clean with a soft dry cloth. Warranty Information This product has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one year from the date of purchase.
