Sharp EL-6810 Series Service Manual

Name : SPLB25A
L R
S A
I Type : CHIP M
POWER SUPPLY AC :
POWER SUPPLIES
AC ADAPTOR
RECHARGEABLE BATTERY
POWER CONSUMPTION
AUTO POWER OFF TIME
MEMORY PROTECT
DIMENSIONS (mm) (When OPEN)
139.0(W) x 174.7 (D) x 9.5(H)
(When CLOSED)
139.0(W) x 89.5 (D) x 13.7(H)
CALCULATIONS
Four arithmetic calculation, Constant calculation, Power
calculation, Chain calculation, Reciprocal calculation, %
calculation, Add-on (discount) calculation
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
SERVICE MANUAL
Name : SPRS512A OTHER SPECIFICATIONS
Type : CHIP
Display :
Memory capacity : 66,838 bytes
DC :
Clock mode :
CR2032 x 1pc
Accuracy :
Display :
Clock function :
0.003W
Telephone mode :
Approx. 7minutes
Schedule mode :
Yes
Memo mode :
Calculator mode :
Currency / unit conversion mode :
Game mode :
Operating temperature : 0˚C to 40˚C (32˚F to 104˚F)
Power supply :
Battery life :
Weight (including battery) :Approx. 105 g (0.231 lb)
Accessories :
SHARP CORPORATION
REPLACEMENT MODEL
MODEL
STANDARD FUNCTION 10 digits
D
I
S
P
L
A
Y
ELEMENT : TN-LCD
S
E UPPER LINE : 12 digits
NUMERAL :
C
LOWER LINE : 12 digits
T
I
O
4.35
N
CHARACTER PITCH : 3.6 (mm)
2.3
KEY SYSTEM : Rubberkey
3 lines of 12 digits
±60 seconds / month at 25˚C / 77˚F
Year, month, day, day of the week, hour, minute, second, AM / PM
12-hour / 24-hour format (switchable), 3 kinds of date type
(switchable), world clock function, daylight saving time
(summer time) display, daily alarm, hourly alarm
Entering and recalling of telephone entry (name, address, E-mail
address, and phone number; and web address (URL))
Entering and recalling of schedule entry (details, year, month,
day, hour, and minute), schedule alarm
Entering and recalling of memo entry
10 digits (with calculation status symbols) arithmetical
calculations, percentage, square root, memory calculation, etc.
5 kinds of currency conversion (editable) and 9 kinds of unit
conversion
2 games
3V ... (DC), lithium battery CR2032 x 1
Approx. 2 years at ambient temperature of 25˚C / 77˚F, assuming
the following daily use : 30 minutes display, alarm sounding for 20
seconds and key touch tone turned on / off 100 times.
1 lithium battery (installed), operation manual
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
EL-6810
1M
PARTS NAME : WK-THA227
SYMBOL : (Refer to above figure)
