- Page 1 8E1+4FE SDH Multiplexer OP-SDH-8E1+4FE Shenzhen Optostar Optoelectronics Co., Ltd 2014. 02(Version 1)
- Page 2 OP-SDH-8E1+4FE 8E1+4FE SDH Multiplexer Overview OP-SDH-8E1+4FE 8E1+4FE SDH Multiplexer is a new generation multi-services transmission and access device based on SDH technologies. The function models design adopts G.783 suggestions and provides complete monitor, access, protection, network management and Ethernet access function. SDH155 can provide 2 STM-1 uplink interfaces, 8 E1 interfaces and 4 10/100BaseT Ethernet interfaces.
- Page 3 OP-SDH-8E1+4FE 8E1+4FE SDH Multiplexer Technical Parameter OP-SDH-8E1+4FE 8E1+4FE SDH Multiplexer Optical interface Interface Standard Complies with ITU-T G.957/G.958 Port Number Transmission distance 0～120Km for option Wave Length 1310nm Rate 155.520Mb/s± 4.6ppm Fiber type ITU-T G.652/G.653, SM Receiving sensitivity <-36 (BER<10)
- Page 4 OP-SDH-8E1+4FE 8E1+4FE SDH Multiplexer Piece Weight Operation Environment Operating temperature -0° C~50° C Storing temperature -20° C~70° C Working Humidity 5%~95 % (no condensation) Storage Humidity 5%~95 % (no condensation) No causticity and solvent, dust free, and no strong magnetic interference.
-
Page 5: Important Notice
The publication of information in this data sheet does not imply freedom from patent or other protective rights of OPTOSTAR or others. Further details are available from any OPTOSTAR sales representative.
