Front Panel Description

PSU Status PSU Status
PSU Status PSU Status
Two bi-colour LEDs confirming the current
status of each PSU. The LEDs are green in
normal operation and flash red if a PSU
fault condition is detected.
Sync Source Selection Sync Source Selection
Sync Source Selection Sync Source Selection
A 3-position toggle switch for selecting the audio sync source. The switch's 'down'
position is latching, while its 'up' position is momentary. Repeated 'upward'
presses on the switch scroll through the possible external sync sources. The
Switch
Position
Centre
Up Increments Sync Source
(Momentary)
Down
Locks Sync To Chosen Source
(Latches)
8 8 8 8
SDI Lock LEDs SDI Lock LEDs
SDI Lock LEDs SDI Lock LEDs
Four tri-colour LEDs, for SDI inputs 1
to 4. Each illuminates when a valid
SDI video signal is detected at its
input, and the colour indicates the
interface standard in use.
adjacent amber LEDs indicate the
Function
currently-selected source.
When the LED for the desired
No Action
source is on, the switch may be
placed in the latching 'down'
Selection
position to prevent inadvertent
further changes of sync source.
Colour SDI Format
Yellow SD-SDI
Green
HD-SDI
Red 3G-SDI
Off No Valid SDI Signal Detected
SRC Control SRC Control SRC Control SRC Control
Four 2-position toggle switches controlling
the four 16-channel output SRCs. The switch
also enables external GPI control of each
SRC.
Switch
Function
Position
Up SRC On
SRC Off, but under external
Down
GPI control
