- Page 1 USER’S MANUAL 6-Piece Rattan Sofa Set HW68449 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. ASSEMBLED BY 2 ADULTS...
- Page 2 Contact our friendly customer service department for help first. Read each step carefully before starting. It is very important to ensure each step followed in correct order, otherwise assembly difficulties may occur. Most of board parts are labeled or stamped on the raw edges. Have a check to make sure all parts are included.
- Page 3 (3 x Corner sofa) (2 x Armless sofa) (1 x Table) Notice: 1. 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. 2. Place the item on a flat ground to adjust and make sure it remains stable 3.
-
Page 4: Part List
Part List Back Frame (2pcs) Seat Frame (2pcs) Side Frame (7pcs) Front Frame (2pcs) Big Corner Frame (3pcs) Small Corner Frame (3pcs) Corner front Frame (3pcs) Table top Frame (1pc) Corner Seat Frame (3pcs) Seat Cushion (2pcs) Long side Table (2pcs) Short side Table (2pcs) Small corner Pillow (3pcs) Back Pillow (2pcs) -
Page 5: Hardware List
Hardware List Bolt M6 x 30 mm (72 pcs) Bolt M6 x 25 mm (48 pcs) M6x1 Washers (72 pcs) Allen key M4 (2 pcs) Plastic feet (24pcs) - Page 6 STEP 1 (2 x Armless sofa assembly) STEP 2 Connect Back Frame (A) & Seat Frame (B) Connect Part from STEP 1 & Side Frame (C) with Bolt (1) & Washers (3) with Bolt (1) & Washers (3) STEP 3 STEP 4 Connect Part from STEP 2 &...
- Page 7 STEP 6 STEP 5 (3 x Corner sofa assembly) Connect Small Corner Frame (F) & Corner Seat Put on Seat Cushion (L) & Back Pillow (N) Frame (G) with Bolt (1) & Washers (3) to complete Chair STEP 7 STEP 8 Connect Part from STEP 6 &...
- Page 8 STEP 10 STEP 9 Connect Part from STEP 9 & Plastic feet (4) Connect Part from STEP 8 & Corner front with Bolt (2) Frame (H) with Bolt (1) & Washers (3) STEP 12 STEP 11 (1 x Table assembly) Connect Table top Frame (I) &...
- Page 9 STEP 14 STEP 13 Connect part from STEP 12 & Long side Table Connect Part from STEP 13 & Plastic feet (4) (J) & Short side Table (K) with Bolt (1) & with Bolt (2) Washers (3) STEP 15 STEP 16 Put on Table Glass (Q) to complete Table FINISH...
