  • Page 1 Heya assembly instructions...
  • Page 2 Heya assembly instructions Important safety instructions When using an electrical furnishing, basic precautions should always be followed, including the following: This furnishing is made for commercial use only. Read all instructions before using this furnishing: DANGER To reduce the risk of electrical shock: 1.
  • Page 3 • 1/4" Allen wrench This sheet covers the necessary steps to fully assemble a Heya bar height runoff table. Begin by inserting the (1609755) 5/16-18 X 2" screw into the foot rail knuckle and threading into the table leg, making sure the knuckle has been mounted in the same orientation as shown in the view above.
  • Page 4 Heya assembly instructions Heya bar height table assembly: Using the view above, fasten the table bracket to the media screen using the supplied 1/4-20 machine screws. Next, insert the (1609756) 1/4-20 X 1.5" screw into the mount puck and thread into the corresponding hole on the media screen.
