Professional duty 72 in. 20-drawer mobile work bench (10 pages)
Summary of Contents for Husky HPRO72HUTCHBLK
Page 1
THANK YOU hutch We appreciate the trust and con dence you have placed in Husky through the purchase of this We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
Table of Contents Table of Contents ..........2 Assembly ............... 6 Safety Information ..........2 Cordless Power Tool Battery Chargers ....11 Warranty ..............4 ....
Page 3
CAUTION: RISK OF ELECTRICAL SHOCK: This unit has one power supply cord. Make sure the cord is unplugged before any servicing or cleaning. HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
Warranty This Husky Professional Grade product includes a Limited Lifetime Warranty, whereas the manufacturer warrants the product to be free from defects in materials and workmanship for the product’s useful life. If any part of this product is found to be defective, the manufacturer’s only obligation, and purchaser’s exclusive remedy, is to provide replacement parts at the manufacturer’s discretion, provided that the product has not...
Page 5
Package Contents (continued) NOTE: Hutch keys are attached to strut. Part Description Quantity Hutch Shelf Transformer HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
Assembly The 72 in. Hutch is designed to speci cally t only on the Husky Professional Duty 72 in. 20-Drawer Workbench , which includes the following products: 72 in. 20-Dr. Professional Duty Workbench Model # HPRO72MWC20BLK SKU # 1000000000 27.5 in. Professional Duty Side Locker...
Page 7
Use 8 pcs M6*48mm ange bolts (BB) to secure the Hutch along the sides and back to the Workbench. Tighten with a 8mm socket or wrench. □ Be careful not to over tighten. HUSKYTOOLS.COM Please c ontact 1-888-HD-HUSKY for further assistance.
Page 8
Attach the LED light □ The LED light has been pre-installed on the shelf. Remove any packing materials and the nylon cable ties bundled at both ends of the LED light. Nylon cable □ Insert the power cable into the end of the LED xture, and reposition so it’s centered on the shelf. Note: The back of the LED xture is magnetic and attaches directly to the articulating holder under the shelf.
Page 9
Secure the LED Transformer (D) to the back of the Hutch using the 2 the Transformer Holders (GG) with 4 pcs Hex socket button cap bolt (EE). □ Tighten with Hex Key (HH). HUSKYTOOLS.COM Please contact 1-888-HD-HUSKY for further assistance.
Page 10
□ Use the Cable clips (FF) to attach the power cord from the LED light and route the wire along the backwall to connect to the Motion Sensor(II). Double-sided tape on back Attach the Storage Hooks □ Hex button botton cap bolt Attach the Storage Hooks (DD) for the power cord on the back of the Hutch with 12 pcs (EE).
This product has been coated with an industrial UV-resistant power coating for a durable and long lasting finish. To help protect the coating, do not allow harsh chemicals to remain on the surface for extended periods of time. HUSKYTOOLS.COM 11 11 Please contact 1-888-HD-HUSKY for further assistance.
Replacement Parts For assistance with replacement parts please call 1-888-HD-HUSKY. Part Part# Description Quantity xxxxxxxxxxxx Badge xxxxxxxxxxxx Kwikset Smartkey® Lock xxxxxxxxxxxx xxxxxxxxxxxx Outlet xxxxxxxxxxxx Outlet Panel Cover xxxxxxxxxxxx Rubber Grommet xxxxxxxxxxxx Storage Hook xxxxxxxxxxxx Storage Hook Bolt xxxxxxxxxxxx Shelf xxxxxxxxxxxx...
Page 13
Questions, problems, missing parts? Before returning to the store call Husky Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday 9 a.m. - 6 p.m., EST, Saturday 1-888-HD-HUSKY HUSKYTOOLS.COM Retain this manual for future use.
