The SUNX' light curtain uses new concepts and
combines even greater safety
with higher productivity
"14 mm (0.551 in) Finger sensing
mImage picture
"25 mm (0.984 in) Hand sensing
"45 mm (1.772 in) Arm / Foot sensing
Type4
LIGHT CURTAIN
SF4B
SF4B
Conforming to Machine
Approved Listing
Directive & EMC Directive
LIGHT CURTAIN
SERIES
SERIES
Conforming to
JIS
OSHA / ANSI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF4B Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sunx SF4B Series

Summary of Contents for Sunx SF4B Series

  • Page 1 Conforming to OSHA / ANSI Conforming to Machine Approved Listing Directive & EMC Directive The SUNX’ light curtain uses new concepts and combines even greater safety with higher productivity "14 mm (0.551 in) Finger sensing mImage picture "25 mm (0.984 in) Hand sensing...
  • Page 2 New concepts in design driving toward greater safety and higher productivity The high level of resistance to disturbance from extraneous light that was a basic feature of the SF4-A series has been maintained in this new series, but a variety of new concepts have been incorporated into the new series, including more compact machine tool size due to a reduction in the safety distance, muting control circuits which have been built into the light curtain, and an override function that allows the manufacturing line to restart operation after the line has stopped even while muting control was active.

  • Page 3: Flexible Cable

    Only 0.197 in from the center of the first beam channel to the edge of the light curtain (Arm / Foot protection type has 15 mm 0.591 Flexible cable Flexible cable releasing releasing mEnlargement Finger protection type Hand protection type Arm / Foot protection type SF4B-F SF4B-H...
  • Page 4 Contributes to miniaturization of machinery Minimum sensing object "14 mm "0.551 in Finger protection type appear Safety distance greatly shortened to improve productivity Safety distance greatly shortened to improve productivity! A finger protection type model improves productivity and Safety distance reduced on-floor costs in line with more compact machinery.
  • Page 5 Unit length protective height, so mounting is possible with no dead zone. ‘ZERO’ dead zone New concept New concept Unit length protective height, so that no dead zone can occur in the interfaces between light curtains when units are connected in series. The equipment can be used with confidence because there are no dangerous openings resulting from dead zone.
  • Page 6 ● Circuit with unreliable PLC Muting sensor Muting lamp External device (Force-guided relay, etc.) Motor, etc. Light curtain Does not comply with safety standards SF4B series Light curtain ● High-cost circuit with exclusive units Muting sensor Muting sensor & CX-400 series ● External device...
  • Page 7 Smooth restart (2 sensors interrupted) Others Others In case of using muting control function Muting unit Muting unit External device monitor Reduces Reduces Total Total SF4B series Cost! Cost! P.12 Safety relay Safety relay Then Then unit unit Unnecessary Unnecessary...
  • Page 8 ●Reducing the number of malfunctions caused by extraneous light A double scanning method and retry processing are two new functions exclusive to SUNX that have been established in the workplace as being effective in eliminating the effects of momentary extraneous light from peripheral equipment.
  • Page 9 Convenient tool facilitates easy beam-axis alignment Beam-axis alignment Beam-axis alignment Beam-axis alignment indicator indicator Reduces installation time significantly Stability Stability The beam-axis alignment indicators that incident light position can be seen at a glance indicator indicator Beam-axis alignment indicators display the beam channels of the light curtain in four blocks.
  • Page 10 NPN polarities in a single model ●A single model has universal applicability Previous model SF4B The SF4B series combines PNP transistor output and NPN transistor output in a single Different model is required A single model is enough! model. Overseas equipment that uses PNP,...
  • Page 11 SF2-EH series to a new series (Note 1). Mounting holes and control circuit connector cables do not need to be changed, and replacement with SF4B series components can be carried out smoothly and there is no need to use replacement parts for previous models, so registration can be only SF4B series (components).
  • Page 12 The SF4B series incorporates a fixed blanking function. The SF4B series incorporates a floating blanking function. The SF4B series is equipped with a fixed blanking function that 1, 2 or 3 non-specified beam channels can be deactivated. If the allows specific beam channels to be selectively interrupted, without number of beam channels that are blocked is less than or equal to the causing the control output (OSSD) to output the OFF signal.
  • Page 13 A single unit can be used for PNP / NPN input switching, reducing the number of parts that need to be registered. m As of June 2005 and based on research conducted by SUNX. P N P P N P...

  • Page 14: Product Configuration

    SF4B PRODUCT CONFIGURATION Mounting bracket and connecting cable are optional. Standard components (8-core cable) Component parts Light curtain Required Mounting bracket (Optional) 8-core bottom cap cable (Optional) 8-core extension cable (Optional, use for cable extension) Cable for series connection (Optional, use for connect in series) Muting control components (12-core cable, with interference prevention wire) Component parts Light curtain...

  • Page 15: Order Guide

    SF4B ORDER GUIDE Mounting bracket and connecting cable are not supplied with the light curtain. Be sure to order them separately. Light curtains Operating range Model No. Number of Protective height Type Appearance (Note 1) (Note 2) beam channels (mm in) SF4B-F23 9.055 SF4B-F31...
  • Page 16 200 to 750 mm 7.874 to 29.528 MS-SFB-4 bracket to the SF4B series. It is installed using two M5 hexagon-socket- Sensing head bolts. (4 pcs. per set for emitter and receiver) surface Four bracket set...
  • Page 17 8-core bottom cap cable specifications. Used to allow connector cables connected to previous light curtains (at the For SF4A-AH -N SFB-CB05-A-N control circuit side) to be smoothly adapted to the SF4B series. (NPN type) Length: 0.5 m 1.640 ft Two cables per set for emitter and receiver, Cable outer diameter: "6 mm "0.236 in...
  • Page 18 SF4B ORDER GUIDE Spare parts (Accessories for light curtain) Intermediate supporting bracket • MS-SFB-2 Designation Model No. Description < > In case of rear mounting Intermediate supporting Intermediate bracket Used to mount the light curtain on the intermediate position. Light curtain MS-SFB-2 supporting MS-SFB-2...
  • Page 19 SF4B OPTIONS Designation Applicable Front protection cover Protection bar set beam channels Finger Hand Arm / Foot Model No. Model No. FC-SFBH-12 MC-SFBH-12 FC-SFBH-16 MC-SFBH-16 FC-SFBH-20 MC-SFBH-20 FC-SFBH-24 MC-SFBH-24 FC-SFBH-28 MC-SFBH-28 FC-SFBH-32 MC-SFBH-32 FC-SFBH-36 MC-SFBH-36 FC-SFBH-40 MC-SFBH-40 FC-SFBH-48 MC-SFBH-48 FC-SFBH-56 MC-SFBH-56 FC-SFBH-64 MC-SFBH-64...
  • Page 20 (Blue) Internal circuit Users’ circuit Non-voltage contact or PNP open-collector transistor Introduction to SUNX sensors that can be used as muting sensors DC 3-wire • Cylindrical Inductive Proximity Sensor Compact Photoelectric Sensor Ultra-slim Photoelectric Sensor U-shaped Micro Photoelectric Sensor CX-400...

  • Page 21: Individual Specifications

    SF4B SPECIFICATIONS Individual specifications SF4B-F Type Min. sensing object "14 mm "0.551 in type Item Model No. SF4B-F23 SF4B-F31 SF4B-F39 SF4B-F47 SF4B-F55 SF4B-F63 No. of beam channels Beam pitch 10 mm 0.394 in Protective height 230 mm 9.055 in 310 mm 12.205 in 390 mm 15.354 in...

  • Page 22: Common Specifications

    SF4B SPECIFICATIONS Common specifications Type Min. sensing object "14 mm "0.551 in type Min. sensing object "25 mm "0.984 in type Min. sensing object "45 mm "1.772 in type Item Model No. SF4B-F SF4B-H SF4B-A ISO 13849-1 / JIS B 9705-1 (Category 4), EN 954-1 (Category 4), EN 61496-1 (Type 4), Applicable standards IEC 61496-1/2 (Type 4), UL 61496-1/2 (Type 4), JIS B 9704-1/2 (Type 4), UL 1998 12 to 64 beam channels type: 0.3 to 9 m...
  • Page 23 The operation indicator is marked as ‘Enabling’ on the unit for SF-C12. Terminals for utilizing the functions of the SF4B series are available. Ambient temperature ( C F) Ambient temperature ( C F)
  • Page 24 SF4B SPECIFICATIONS Handy-controller Model No. SFB-HC Item 24 V DC 10 % Ripple P-P10 % or less (common to light curtain power supply) Supply voltage Current consumption 65 mA or less RS-485 two-way communications (Specific procedure) Communication method 4-digit red LED display 2 (Selected beam channels, setting contents etc.

  • Page 25: I/O Circuit Diagram

    SF4B I/O CIRCUIT AND WIRING DIAGRAMS I/O circuit diagram < > < > In case of using I/O circuit for PNP output In case of using I/O circuit for NPN output Emitter Emitter Color code of mating cable Color code of mating cable (Brown) (Brown) (Shield) Output polarity setting wire...

  • Page 26: Connection Example

    SF4B I/O CIRCUIT AND WIRING DIAGRAMS Connection example Standard components (8-core cable): Interlock function ‘enabled (manual reset)’, external device monitoring function ‘enabled’ < > In case of using I/O circuit for PNP output Color code of mating cable The diagram at left shows the configuration when using PNP output, Emitter interlock function ‘enabled (manual reset)’...
  • Page 27 SF4B I/O CIRCUIT AND WIRING DIAGRAMS Connection example Muting control components (12-core cable, with interference prevention wires): Interlock function ‘disabled (automatic reset)’, external device monitoring function ‘disabled’ < > In case of using I/O circuit for PNP output Color code of mating cable The diagram at left shows the configuration when using PNP output, Emitter (Brown)
  • Page 28 I/O CIRCUIT AND WIRING DIAGRAMS SF-C11 Be sure to use the following connection cables when connecting this product to the light curtain. SF4B series Wiring diagram (Control category 4) SFB-CB05 (cable length: 0.5 m 1.640 SFB-CB5 (cable length: 5 m 16.404...
  • Page 29 SF4B I/O CIRCUIT AND WIRING DIAGRAMS SF-C13 SF4B series Wiring diagram (Control category 4) For PNP output (minus ground) For NPN output (plus ground) • Connect the light curtain control outputs OSSD1 and OSSD2 to S1 • Connect the light curtain control outputs OSSD1 and OSSD2 to S4 and S2 respectively and ground the side.

  • Page 30: Precautions For Proper Use

    SF4B PRECAUTIONS FOR PROPER USE Interlock function Emission halt function • When the light curtain has been interrupted and control output • This function stops the emission process of the emitter. You can select whether emission is on or halted by means of the (OSSD1, OSSD2) is OFF, the interlock function keeps the control connection status for the emission halt input / reset input wire output at OFF until a reset signal is input.

  • Page 31: External Device Monitoring Function

    SF4B PRECAUTIONS FOR PROPER USE External device monitoring function Muting function • This is the function for checking whether the external safety relay • Incorrect using of the muting control may cause any connected to the control output (OSSD1, OSSD2) performs accident.

  • Page 32: Override Function

    SF4B PRECAUTIONS FOR PROPER USE < > Time chart Specification for muting sensor Muting sensor A Operation when sensor is ON Operation when sensor is OFF 30 ms to less than 3 sec. ON with ‘Dark-ON’ condition (photoelectric sensor, etc.) Muting sensor B ON with ‘Normally open’...

  • Page 33: Series Connection

    SF4B PRECAUTIONS FOR PROPER USE Series and parallel mixed connection Series connection • This is the configuration for connecting multiple sets of emitter and Connectable up to 3 sets of light curtains (however, 192 beam channels max.) receiver facing each other in mixed series and parallel •...
  • Page 34 SF4B PRECAUTIONS FOR PROPER USE Part description and function Top end Receiver Emitter Beam-axis alignment indicator Beam-axis alignment indicator [RECEPTION] [RECEPTION] Operation indicator [OSSD] (Note 1) OSSD indicator [OSSD] Incident light intensity indicator [STB] Incident light intensity indicator [STB] Beam-axis Fault indicator [FAULT] Fault indicator [FAULT] alignment...

  • Page 35: Safety Distance

    SF4B PRECAUTIONS FOR PROPER USE Safety distance • When this device is used in the ‘PSDI mode’, an appropriate control circuit must be configured • Calculate the safety distance correctly, and always between this device and the machinery. For details, maintain a distance which is equal to or greater than be sure to refer to the standards or regulations the safety distance, between the sensing area of this...

  • Page 36: Influence Of Reflective Surfaces

    Since the OFF signal of this device might cause : Maximum halting time of machinery (sec.) malfunction, perform the connecting paying attention : Response time of the SF4B series 0.014 (sec.) SF4B to the input response time of the machine to be C: Additional distance calculated from the size of the minimum sensing object of the light curtain (mm) connected to this device.
  • Page 37 SF4B PRECAUTIONS FOR PROPER USE Handy-controller This device enables to set each function using the handy-controller (SFB-HC)(optional). However, a handy-controller cannot be used with the SF4B- -01 (refer to p. 14) and the SF-C14EX-01 (refer to p. 43). Among the functions, the contents related to the safety distance such as the size of the minimum sensing object and response time are varied depending on the setting condition.
  • Page 38 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ SF4B- Light curtain Assembly dimensions Mounting drawing for the light curtain on which the standard mounting brackets (MS-SFB-1) and the intermediate supporting brackets are mounted.
  • Page 39 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ SF4B- Light curtain Assembly dimensions Mounting drawing for the light curtain on which the dead zoneless brackets (MS-SFB-3) and the intermediate supporting brackets are mounted.
  • Page 40 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ SF4B- Light curtain Protection bar dimensions Mounting drawing for the light curtain on which the front protection unit (MC-SFBH- ) is mounted.
  • Page 41 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ MS-SFB-2 Intermediate supporting bracket (Accessory for light curtain) 0.374 0.228 22.2 1.575 0.874 (length 0.512 1.457 12 0.472) 0.327 0.472 0.335 0.079...
  • Page 42 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ MS-SFB-4 Pitch adapter bracket (Optional) 0.331 0.315 0.118 63.5 0.709 2.500 74.5 2.717 85.5 45.5 0.276 2.933 3.366 1.791 (Sliding range) 0.394...
  • Page 43 SF4B DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/ SF-C11 SF-C12 Control unit (Optional) Control unit (Optional) 2-"6 "0.236 5.000 67.5 2-"10 "0.394 2.657 3.150 0.276 0.236 1.181 0.256 54.1 0.827...
  • Page 44 Supports both PNP and NPN polarities ● Equipped with a digital indicator so that error details can be understood at a glance! APPLICATION EXPANSION UNIT FOR SF4B SERIES SF-C14EX SERIES All information is subject to change without prior notice. SUNX Limited...
