- Page 1 INSTRUCTIONS AND USER MANUAL PANDuo pH Turboxy Cl T www.avadypool.com...
-
Page 2: Table Of Contents
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 TABLE OF CONTENTS 1 WARNING AND ADVICE .................... 4 Guarantee and Warning ..................... 4 Shipping and transporting ....................5 Proper use of the pump ..................... 5 Risk ............................ 5 Toxic and/or dangerous liquid dosage ................6 Assembling and dismantling the pump ................ - Page 3 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Wintering ..........................26 Recommended and non-recommended chemicals ..............27 Shock Chlorination ........................27 7 AFTER SALES SERVICE ................... 27 SPARE PARTS LIST ....................... 28...
-
Page 4: Warning And Advice
(www.avadypool.com) within one month. The warranty runs for 12 months from the date of purchase but this period may not exceed 18 months from the date of sale by AVADY POOL. The warranty consists of the direct replacement of the sensor identified as being faulty by our Technical Department, or its repair, after examination by our Technical Department, excluding any other compensations of whatever form. -
Page 5: Shipping And Transporting
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Shipping and transporting No matter what the means of transport employed, delivery of the pump, even when free to purchasers or the addressee’s domicile, is always at the purchaser’s risk. Claim for any missing materials must be made within 10 days of arrival, while claims for defective materials will be considered up to the 30th day following receipt. -
Page 6: Toxic And/Or Dangerous Liquid Dosage
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 In case of damage of power supply cord please ask the repair to our technical assistance or qualified and authorized personnel. When you decide to make no further of an installed pump, make sure to disconnect it from the power supply. -
Page 7: Description Of Pan Duo Ph Turboxy
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 2 DESCRIPTION OF PAN DUO PH TURBOXY The PAN DUO PH TURBOXY is characterized by its ability to measure the pH (0 to 14 pH) and some chlorine (between 0 and 4 ppm) thanks to its placed probes in the filtration circuit which analyzes the water of your pool. -
Page 8: Description Of The Plugs Of The Pan Duo Ph Turboxy
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 2.2 Description of the plugs of the PAN DUO PH TURBOXY 230V power supply cable pH probe plug Turboxy probe plug pH low level Chlorine low level 3 RECOMMENDATIONS AND INSTALLATION Recommendations If the temperature exceed 30°... -
Page 9: Installation
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 3.2 Installation 3.2.1 Prepare the sensor for the start-up 2) Leave the sensor submerged 1) Remove the sensor's in tap water for at least 20 protective minutes, before proceeding keep it to re-use it for with the calibration. - Page 10 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 3.2.4 Calibration of the pH sensor Remove the sensor from its soaking water indicated in STEP 2 and remove any excess water ↓6.9pH 1.2Cl↑ PRESS THE ESC KEY AT ANY TIME TO EXIT THE CALIBRATION PROCEDURE 1.2Cl↑...
- Page 11 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 3.2.5 Hydraulic circuit The hydraulic tube is placed in the same way on Tube the strainer and the pump. Connector 1 : Slide the tube through the nut 2 : Push the tube down to the bottom of the Valve conical connector 3 : Hand tighten the nut onto the connector...
- Page 12 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Analyze the rate of chlorine with a reactive DPD1 and memorize the obtained value Take the water near the discharge. Measure the ↓ 7.3pH 1.2Cl ↑ chlorine Cl level in mg / L (ppm) with a DPD1 photometer or dipstick or pelletizer.
-
Page 13: Avanced Unit Settings
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4 AVANCED UNIT SETTINGS 4.1 Adjusting the pH setpoint ↓6.9pH 1.2Cl↑ To adjust the chlorine setpoint, press one more time the MENU / ESC. 1.2Cl↑ ↓6.9pH Setting range of 6,5 to 7,6 pH SETPOINT 7.4pH WHEN THE SET BUTTON IS RELEASED,... -
Page 14: Adjusting The Chloring Setpoint (Cl)
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4.2 Adjusting the Chloring setpoint (Cl) ↓6.9pH 1.2Cl↑ To adjust the chlorine setpoint, press one more time the MENU / ESC. 1.2Cl↑ Setting range Of 0.5 to 4.0 Cl SETPOINT 1.4 Cl WHEN THE SET BUTTON IS RELEASED, THE VALUE WILL BE MEMORIZED... - Page 15 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4.3.2 Proportional activation The device sets longer dosing periods when the measured value is far from the desired value (set point). The closer the measured value approaches the desired value (setpoint), the shorter is the dosing period. Water volume Pump Acti Time Pump Acti Time...
-
Page 16: Turboxy Duo Ph Cl °C Web Settings
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Device settings 4.4.1 pH menu ↓ 7.5pH 1.2Cl↑ Tip PRESS THE ESC KEY AT ANY TIME TO EXIT MENU. 1.2Cl↑ ↓7.5pH LANGUAGES : LANGUAGE FRANÇAIS ENGLISH DEUTSCH NEDERLANDS ENGLISH PORTUGUES ESPANOL ITALIANO CONFIGURATION CONFIGURATION : Cl / pH / SYS... - Page 17 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4.4.2 Cl menu ↓ 7.5pH 1.2Cl↑ Tip PRESS THE ESC KEY AT ANY TIME TO EXIT MENU 1.2Cl↑ LANGUAGES : FRANÇAIS ENGLISH SVENSKA DEUTSCH NEDERLANDS LANGUAGE ENGLISH PORTUGUES ESPANOL ITALIANO CONFIGURATION : CONFIGURATION Cl / pH / SYS PRIMING :...
- Page 18 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4.4.3 System menu « SYS » Tip PRESS THE ESC KEY AT ANY TIME TO EXIT ↓ 7.3pH 1.2Cl/↑ MENU LANGUAGES : FRANÇAIS ENGLISH SVENSKA DEUTSCH NEDERLANDS LANGUAGE PORTUGUES ESPANOL ITALIANO ENGLISH Si oui, l’affichage par défaut montrera sur la CONFIGURATION : Cl / pH / SYS...
- Page 19 Instructions and user manual PANDuo pH Turboxy NOT044ENV02 4.4.4 Overdosing alarm The pump blocks its dosing and displays an alarm message when it has dosed more than the volume indicated in the alarm menu for 4 consecutive hours. This alarm allows dynamic monitoring of any potential overdosing Adjusting the overdose alarm (cf 4.4.5): above the OVERDOSING ALARM...
-
Page 20: Pan Duo Ph Turboxy Standby Mode
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 PAN DUO PH TURBOXY Standby mode To place the PAN DUO PH TURBOXY in standby mode, press the ▲and ▼ keys simultaneously for 5 seconds. To exit standby mode, repeat the same operation. PAN DUO PH TURBOXY Priming There are 2 manners to priming the PAN DUO PH TURBOXY : 1°: Priming of pumps at the same time :... -
Page 21: Alarms And Displayed Symbols
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Alarms and displayed symbols Message Meaning Action / and \ alternatives The pump is currently dosing Dosing has stopped : Wait for: Either in the pause cycle The end of the pause cycle Either by the activation delay The end of the activation delay ↑... -
Page 22: Pairing The Pan Duo Ph Turboxy To Avadyconnect (Optional)
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 Pairing the PAN DUO PH TURBOXY to AvadyConnect (OPTIONAL) In case of change of the PAN DUO PH TURBOXY on the installation the pairing of the new device will have to be realized so that its information can go back up on the site www.avadyconnect.com. 1) Bring AvadyConnect near the PAN DUO PH TURBOXY 2) Go to the network menu of PAN DUO PH TURBOXY as below ↓... -
Page 23: Maintenance
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 6 MAINTENANCE 6.1 Wear parts of the pump To protect the quality of your device, we advise you (*) to change the p arts of following wears: MEASURED FREQUENCY CODE DESCRIPTION OF PARTS PRODUCTS pH- or pH+ AYAC100152... -
Page 24: Cleaning Electrode Of The Probe Turboxy
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 6.2 Cleaning electrode of the probe TURBOXY After overchlorination with the TURBOXY chlorine probe in place, or a prolonged shutdown of several days, the electrode can be oxidized and no longer allow the chlorine level to be measured correctly. -
Page 25: Remplacement Of The Peristaltic Tube
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 6.4 Remplacement of the peristaltic tube Removal of the old tube Setting up the new tube Ensure that the tube is properly lubricated with silicone grease... -
Page 26: Wintering
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 6.5 Wintering 6.5.1 Probe wintering It is important to know that when your device is winterized, it is the peristaltic tube that must be protected. It is therefore recommended to pump clean water to rinse the peristaltic tube ... -
Page 27: Recommended And Non-Recommended Chemicals
Instructions and user manual PANDuo pH Turboxy NOT044ENV02 6.6 Recommended and non-recommended chemicals It is recommended to use sulfuric acid, which is 100% compatible with the Santoprene tube. Do not use the TURBOXY probe in some salt water. ... -
Page 28: Spare Parts List
250mL AVADY POOL - 9, Chaussée Jules César, Bâtiment 4 Hall 406 - 95520 OSNY - France Tél : +33 (0)1 34 48 16 03 - Fax : +33 (0)1 78 76 73 95 - Mail : contact@avadypool.com...
