Frigidaire FEC30S6H Factory Parts Catalog page 5

A= FEC30S6H (FEC30S6HSA)
B= FEC30S6H (FEC30S6HBA)
# = Func tional Part
* = Non-Illustrated Part
FEC30S6H
MAINTOP/SUR FACE UNITS
POS. NO PART NO
15 318178101
15A# 318178002
15B# 318178100
16 318079311
16 318079310
20 318121902
23 5303297401
46 318077211
52 318122007
52B 318122006
159 318125111
162 318125200
163 08007817
164 318125301
*# 5303323364
* 08016432
* 5303323129
* 5303300265
* 5303323131
DE SCRIP TION
A B El e ment-surface,2100W
A B El e ment-surface,1000/2000W
A B El e ment-surface 1200W
A Glass Main Top & frame white
B Glass Main Top & frame black
A B Bracket
A B Panel-access
A B Burner Box
A B Spring el e ment mtg
A B Spring el e ment mtg
A B De flec tor
A B Heat de flec tor
A B Spacer
A B Shield
A B Bx & wires assy
A B Screw, 8-18 X 3/8
A B Screw, 8 X ¾
A B Screw, 8-18 X ½
A B Screw, 8-32 X 7/16
5
Pub li ca tion No.
5995323911
05/99
