Frigidaire FEC30S6D Factory Parts Catalog

Electric cook-top range
Hide thumbs

Advertisement

Quick Links

8"
"
FEC30S6D.eps L21C0005.eps L21T0002.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FEC30S6DQA
3805424354041
Series
30" elec
Color
stainless
Market
North America
Wiring Diagram
318046805
Owner's Guide
318200612
Installation Instructions 318201410
318046805.eps
Publication No.
5995422796
04/11/23
(EN/SERVICE/ECL)
377
ELECTRIC COOK-TOP
RANGE
Model No.
FEC30S6D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FEC30S6D

  Summary of Contents for Frigidaire FEC30S6D

  • Page 1 8" " FEC30S6D.eps L21C0005.eps L21T0002.eps ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 Product No. FEC30S6DQA 3805424354041 Series 30" elec Color stainless Market North America Wiring Diagram 318046805 Owner's Guide 318200612 Installation Instructions 318201410 ELECTRIC COOK-TOP 318046805.eps FEC30S6D Publication No.
  • Page 2: Control Panel

    Publication No: 5995422796 FEC30S6DQA CONTROL PANEL 11/04...
  • Page 3 POS. NO PART NO. 318096327 318196635 51 # 318044820 54 # 318220071 54A# 318220072 5303323134 318148900 5303300265 5303323140 # Functional Parts * Non-Illustrated Parts FEC30S6DQA CONTROL PANEL DESCRIPTION Box, instrument mtg Knob, control, bisque Light, indicator, red Switch, surface unit, small Switch, surface unit, large Screw, 8-32 x 0.188 Bushing, switch...
  • Page 4 Publication No: 5995422796 FEC30S6DQA MAIN TOP/SURFACE UNITS 11/04...
  • Page 5 POS. NO PART NO. 15 # 318198817 15A# 318198812 15B# 316224200 318079399 318121902 318194703 318077232 318122007 318122010 318122006 318125113 318014110 318078525 08016432 5303323129 # Functional Parts * Non-Illustrated Parts FEC30S6DQA MAIN TOP/SURFACE UNITS DESCRIPTION Element, surface, small/6", 1200 W Element, surface, 8", 2200 W Element, surface, 9", 2500W, radiant Main Top Assy, glass/steel, bisque/black Bracket, retainer...
  • Page 6: Wiring Diagram

    Publication No: 5995422796 FEC30S6DQA WIRING DIAGRAM 11/04...
