Tsubaki TSBSS Series Instruction Manual

Shock relay

Advertisement

Quick Links

SHOCK RELAY
SHOCK RELAY
SHOCK RELAY
SHOCK RELAY
TSBS S S S S S S S Series
TSB
TSB
TSB
INSTRUCTION MANUAL
! ! ! !
1. Make sure you read this instruction manual thoroughly before installing,
wiring, operation and inspecting this SHOCK RELAY.
2. Please make sure that this instruction manual accompanies the SHOCK
RELAY to the end user.
3. Product specification are subject to change for improvement without
notice.
4. Disconnect power. Always lock out power switch before installing,
removing, or servicing unit. Comply with Occupational Safety and Health
Standards 1910. 147 "The Control of Hazardous Energy (Lock Out/Tag
Out)."
5. Install in proper enclosure in accordance with NEMA 250-1991
"Enclosures for Electrical Equipment (1000Volts Maximum)" and NFPA496
1993 edition "Purged and Pressurized Enclosures for Electrical
Equipment, 1993 Edition." When revisions of these standards are
published, the updated edition shall apply.
6. Guards must be provided on all power transmission and conveyor
applications in accordance with provisions of ASME B15.1-1996 "Safety
Standards for Conveyors and Related Equipment, or other applicable
standards. When revision of these standards are published, the updated
edition shall apply.
! ! ! !
■ If danger is expected from your application, take the necessary
steps to ensure that it operates safely.
■ If your Tsubaki Emerson product does not operate normally, take
care to ensure that dangerous operating conditions do not occur.
■ Wear suitable clothing and protective equipment (safety glasses,
gloves, safety shoes, etc.)
Keep your work place tidy and safe to prevent accidents.
Series
Series
Series
WARNING
WARNING
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
TSUBAKI E E E E & & & & M M M M CO.
TSUBAKI
TSUBAKI
TSUBAKI
E E E E HF
HFSS
HF
HF
SS05 05 05 05. . . . 06 06 06 060 0 0 0 1 1 1 1 - - - - 9 9 9 9
SS
SS
CO.
CO.
CO.
20 20 20 201 1 1 1 3 3 3 3 . . . . 12.1
12.1
12.1
12.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSBSS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Tsubaki TSBSS Series

  • Page 1 Keep your work place tidy and safe to prevent accidents. TSUBAKI TSUBAKI TSUBAKI TSUBAKI E E E E & & & & M M M M CO. 20 20 20 201 1 1 1 3 3 3 3 ..12.1 12.1 12.1...
  • Page 2 Preface Thank you for purchasing the Shock Relay TSBSS series. This instruction manual describes everything from installation to adjustment. Be sure to read this manual carefully before using your Shock Relay. When delivering a device containing the Shock Relay, be sure that this instruction manual is included.
  • Page 3 Dimensions ・ ・ ・ ・ Shock relay Attachment Screw Cover (Unit mm 1inch=25.4 mm)
  • Page 4 ・ ・ ・ ・ External 2-phase CT Details for installation holes...
  • Page 5: Specifications

    Specifications Series TSB SS Current Setting * Model Range 0.5-6A 3-30A 5-60A Time Setting * Starting Trip Delay Start Time 0.2-30s Trip Time Shock Time 0.2-10s Accuracy Current ±10% (Full scale ) Control Power Supply 100~240VAC±10%, 50/60Hz 600VAC, 50/60Hz * Maximum motor voltage Current Sensing method 2 Integral Current Transformer...
  • Page 6: Installation

    Installation 1. Environmental specifications Install the Shock Relay in the following environment. • Temperature: -20 to +60℃ not in direct sunlight. • Humidity: 45~85% relative humidity without condensation and freezing. • Place: Indoors, no water splash. • Atmosphere: Free from dust, corrosion gas, and oil mist. •...
  • Page 7: Current Transformer

    Current Transformer Select the number of wires passing through the CT (Current Transformer) by using the following table for best performance. When two motor leads pass through the CT, the current sensed by the CT is twice the motor current flowing through the motor lead. AC 200 ~ 230 Volt Motor AC 400 ~ 460 Volt Motor Motor...
  • Page 8 TSB2CT( ( ( ( External 2-phase CT) ) ) ) ・ ・ ・ ・ Specifications Model No. TSB2CT100 TSB2CT200 TSB2CT300 Class Rated primary current 100A 200A 300A Rated secondary current Rated burden Rated frequency 50/60Hz Approximately weight 0.5kg ・ ・ ・ ・ Installation Procedure 1.
  • Page 9 10. Construction OC LED ①START TIME knob ③SHOCK TIME knob 0.2-30sec 0.2-10sec ②CURRENT knob MON LED TEST L1 L2 95 96 98 RESET POWER OUTPUT INPUT Description Shock Relay senses the motor current passing through the two CTs and automatically detects the starting of the motor.
  • Page 10: Troubleshooting

    11. Set up 1. Set START TIME knob (start-up delay) at the start-up time if the start-up time is known. Set START TIME knob (start-up delay) at the maximum if the start-up time is unknown. 2. Set SHOCK TIME knob (trip delay timer) at the desired trip time. 3.
  • Page 11: Maintenance

    Shock Relay for a new one before trouble occurs. 15. Point for safe use (1) Take measures beforehand to prevent danger when using a TSUBAKI product. (2) If our product begins to operate improperly, be sure to take measures to prevent a dangerous situation from arising.
