CTRL BOX
CTRL BOX
The CTRL BOX is our official
offering for remote preset
selection and remote tap tempo
/ HOLD engagement for the
Delay Llama XTREME!
To remotely engage presets via
the CTRL BOX:
1.
Connect a stereo-to-stereo
patch cable from the PS output
jack on the CTRL BOX to the PS
input jack on your Delay Llama
XTREME
2.
Press the numbered
footswitch corresponding to the
preset you wish to engage
To remotely tap your preferred
tempo in via the CTRL BOX:
1.
Connect a mono-to-mono
patch cable from the TAP output
jack on the CTRL BOX to the TAP
input jack on the Delay Llama
XTREME
2.
A prolonged press will engage
the HOLD function
Advertisement
Table of Contents
Related Manuals for JAM Pedals CTRL BOX
Summary of Contents for JAM Pedals CTRL BOX
- Page 1 Delay Llama XTREME! To remotely engage presets via the CTRL BOX: Connect a stereo-to-stereo patch cable from the PS output jack on the CTRL BOX to the PS input jack on your Delay Llama XTREME Press the numbered footswitch corresponding to the...
- Page 2 *Notes: In order to save presets while the CTRL BOX’s remote tap tempo is connected to your Delay Llama XTREME, you would need to simultaneously hold the middle foot switch on the Delay Llama XTREME and TAP TEMPO on the CTRL BOX. Alternatively,...
