Amigo APL52X Quick Installation Manual

S tep 5
Access Point Setup
(1)
Open a web browser on your computer. In the
address bar of the web browser, enter
192.168.1.254 and enter.
(2) A login screen will appear. By default, the username
of the Access Point is admin and the password is
admin. Enter the current username and password of
the Access Point and then click Login.
(Username: admin, Password: admin)
(3)
TThe Access Point User Interface will appear. This
device can operate in Access Point operating mode.
Model variants
Trade Name Model No. Difference
Amigo Technology APL52X 2x2 11ax AP
Amigo Technology APL54X 2x2 11ax AP with LTE option (module)
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this
device could void the user's authority to operate the equipment.
RF Exposure warning
This equipment must be installed and operated in accordance with
provided instructions and the antenna(s) used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any other
antenna or transmitter. End-users and installers must be provide with antenna
installation instructions and transmitter operating conditions for satisfying RF
exposure compliance.
This radio transmitter FCCID: RC6-APL5XX has been approved by FCC to
operate with the antenna types listed below with the maximum permissible
gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the
maximum gain indicated for that type, are strictly prohibited for use with this
device.
Antenna List (for APL54X)
No. Manufacturer Part No. Antenna Type
1
ANJIE AELQ2S-W6159 Dipole
2
ANJIE AELQ2S-W6959 Dipole
Quick Installation Guide
Indoor A ccess P oint
Max Antenna Gain
4.4 dBi
3.0 dBi
