Desktop solder smoke absorber that can be mounted horizontally or vertically
•
A third mounting position is also available with an optional arm stand
Model No.
Power consumption
Noise level
Maximum suction capacity
Air velocity
Dimensions
Weight
Filter size
* Noise level is measured at a distance of 1m from the face of HAKKO 420.
* Maximum suction capacity is measured in the condition with filter.
Part No.
FA-400
Smoke absorber/Desktop type
50Hz : 15W
60Hz : 13W
50Hz : 48dB
60Hz : 51dB
3
Vertically : 1.0m
/min. (50Hz) / 1.1m
Horizontally : 0.4m
Vertically : 1.0m/s (50Hz) / 1.1m/s (60Hz)
Horizontally : 2.6m/s (50Hz) / 2.9m/s (60Hz)
166(W)×212(H)×113(D)mm
0.93kg
130(W) ×130(H) ×10(D)mm
HAKKO FA-400 Smoke absorber, Filter and Instruction manual
FA400
3
/min. (60Hz)
3
/min. (50Hz) / 0.5m
Packing List
3
/min. (60Hz)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hakko Electronics FA-400
Summary of Contents for Hakko Electronics FA-400
- Page 1 * Noise level is measured at a distance of 1m from the face of HAKKO 420. * Maximum suction capacity is measured in the condition with filter. Part No. Packing List FA-400 HAKKO FA-400 Smoke absorber, Filter and Instruction manual...
- Page 2 Horizontally/vertically mountable "2-Way Plus" tabletop smoke absorber In addition to horizontal and vertical mounting, an optional arm stand allows a third mounting style. - When vertically mounted: - When horizontally mounted: Can be absorbed widespread smoke. Powerful absorption at closer area with high flow rate. Because of low height, it gives less shade keeping your working area light.
- Page 3 Size comparison to previous model (HAKKO 493) Maintenance • The absorption force at the filter decreases gradually over time as the absorber is used. When the filter surface becomes completely white, the filter should be replaced. Be careful that moisture, etc does not get on the filter. Part No.
- Page 4 Part No. Name Specifications C1568 Arm stand w/ knobs B1166 Knob ESD, set of 2 Arm stand...
